Crown (Middleby)  |  SKU: EL-40F

Crown (Middleby) EL-40F Steam Kettles

$37,059.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Parts list Middleby financial flyer Crown steam group letter Installation & operation manual Warranty sheet
Related Searches
Steam Cooking Equipment Steam Kettles

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Crown EL-40F | 40-Gallon Stationary Electric Tri-Leg Kettle

Full-jacket, self-generating steam kettle for high-volume, high-acid cooking

Produce perfectly consistent soups, sauces, stocks and more with the Crown EL-40F. This 40-gallon (152 L) kettle surrounds your product with gentle, even steam heat, while heavy-duty stainless construction, built-in safety features and included accessories keep your kitchen running safely and efficiently shift after shift.

What’s in the box
  • 40-gal electric, full-jacket stationary kettle
  • 2 in. sanitary draw-off valve with perforated strainer
  • Counter-balanced, spring-assist stainless steel domed cover
  • Factory-mounted faucet bracket
  • Tri-leg base with adjustable flanged feet for floor anchoring
Key advantages
  • Self-contained, closed steam system—no external boiler required
  • Full jacket envelops 100 % of the kettle for rapid, uniform heating
  • 316 SS interior liner resists corrosion from tomato-based and other acidic foods
  • Durable 304 SS exterior with easy-clean #4 finish
  • Thermostatic control (165 °F – 285 °F / 74 °C – 140 °C) with pilot lights, pressure gauge & low-water cutoff
  • Standard 18 kW electric elements (24 kW or 33 kW available) in a wide range of single- and three-phase voltages
  • ASME code stamped, National Board registered pressure vessel
  • Certified cCSAus & NSF for worry-free installation
  • 10-year hemispherical kettle body warranty
Specifications
Model EL-40F (stationary, tri-leg)
Capacity 40 gal / 152 L
Heating method Self-generating closed steam jacket, electric
Standard power 18 kW  | 208, 220, 240, 380/220, 415/240 V — 1 ɸ or 3 ɸ
Optional power 24 kW or 33 kW (208–600 V, 3 ɸ)
Temperature range 165 °F – 285 °F (74 °C – 140 °C)
Operating pressure Max 50 psi (345 kPa)
Interior material 316 stainless steel
Exterior material 304 stainless steel, welded #4 finish
Draw-off valve 2 in. sanitary, with perforated strainer
Cover Spring-assist, counter-balanced, hinged SS dome
Overall height 70.5 in. (1791 mm) with cover open
Ship weight ≈ 420 lb (191 kg)
Certifications ASME, cCSAus, NSF
Warranty 10 yr kettle body, 1 yr parts & labor
Popular factory options
  • 3 in. draw-off valve with strainer (TVT-3)
  • Etched gallon or litre markings
  • Single or double pantry faucets / kettle fillers
  • Higher-power 24 kW or 33 kW elements
  • One-piece lift-off or two-piece hinged covers
  • Graduated measuring strip, heat shield & more
Important: This equipment is intended for commercial kitchens only. Follow all local codes and have installation performed by a qualified electrician.

Need financing? Ask about Middleby Equipment Financing for fast credit decisions and affordable monthly payments.

Features & Specs

Manufacturer

Crown (Middleby)

Certifications

NSF, cCSAus

Height

36.25in

Width

37.0in

Depth

46.88in

Shipping Weight

420.0lbs

Kettle Jacket

full jacket

Capacity

30 - 45 gallon

Kettle Liner

316 stainless steel

Base

tri-leg

Specifications

Stationary Kettle, electric, 40 gallon capacity, full jacket, thermostatic control, 2" draw-off, includes: perforated strainer, counter balanced hinged cover & faucet bracket, 316 stainless steel interior liner, 304 stainless steel exterior, tri-leg, cCSAus, NSF
