Crown (Middleby) DCX-2-6-6 Steam Kettles
Description
DCX-2-6-6 Two-Compartment Convection Steamer
with (2) 6 Gallon Kettles
Direct-steam cabinet base with integral sink & deck-mount faucet
Built for high-volume kitchens that need serious versatility in a compact footprint, the Crown DCX-2-6-6 pairs a 6-pan, twin-compartment convection steamer with (2) 6 gal tilting kettles. 316 stainless steel interiors, precise 60-minute timers and an integrated hand-sink with swing nozzle make batch cooking, re-thermalizing, blanching and small-batch sauces faster, safer and easier than ever.
Why You’ll Love It
- Direct steam operation—ready to cook with 15-45 psi house steam (internal PRV regulates to 7 psi).
- Two independent 3-pan chambers (3 x 12" × 20" × 2.5" per side) for a total of 6 full-size hotel pans.
- Heavy-duty 316 SS cooking chambers resist chlorides and harsh cleaners; removable pan racks for easy wash-down.
- 304 SS exterior with #4 sanitary finish—built for the rigors of institutional and restaurant kitchens.
- (2) 6 gal tilting kettles share the same steam source for gravies, soups and sauces right at the cookline.
- Positive-lock doors with full-perimeter gaskets prevent energy loss; drip trough directs condensate to drain.
- Independent 60-minute mechanical timers with cooking/ready lights & end-of-cycle buzzer.
- Integrated hand-sink, deck-mount faucet valve & swing nozzle for quick kettle filling and compartment cleanup.
- 60" cabinet base with (3) hinged storage doors; fully removable side panel for service access.
- Four 6" stainless legs with adjustable flanged feet for floor anchoring.
- Certified NSF & CSAus; 120 V / 1-Ph / 4 A control circuit—no high-voltage hookup required.
Specifications
| Model | DCX-2-6-6 |
|---|---|
| Compartments | 2 pressureless, convection steam chambers |
| Pan Capacity (per compartment) | 3 × 12" × 20" × 2 ½" pans (6 total) |
| Kettles | (2) 6 gal / 23 L tilting, direct-steam kettles |
| Interior Material | 316 stainless steel, fully welded & insulated |
| Exterior Material | 304 stainless steel, #4 finish |
| Base Width / Footprint | 60" W cabinet base (overall length 55.5" nominal) |
| Steam Connection | ¾" IPS, 15-45 psi (1.0-3.1 bar) house steam |
| Water Connections | (2) ⅜" OD cold & hot, 25-50 psi for faucet & drain tempering |
| Drain | 2" IPS to open floor drain; 1 ⅛" OD sink drain |
| Electrical | 120 V, 50/60 Hz, 1-Ph, 4.0 A total (2 A per compartment) |
| Legs / Feet | (4) 6" stainless legs with adjustable flanged feet |
| Certifications | NSF, CSAus |
| Shipping Weight | Approx. 830 lb / 376 kg |
Popular Factory Options (add-on)
- Stainless steel rear panel or frame
- Etched gallon or litre markings
- One-piece lift-off lids & stainless baskets
- Spray-and-rinse assembly or ball-float trap
- Load-compensating timers & correctional package
For peak performance and to maintain warranty coverage, incoming water must meet Crown’s quality standards (TDS < 60 ppm, pH 6.8-7.3, hardness < 35 ppm). Water treatment systems are available.
