Convotherm

Convotherm FLT0032-COV Reverse Osmosis Water Filtration System with 5-Gallon Hydropneumatic Storage Tank, 175 GPD, Non-Electric

SKU: FLT0032-COV
$1,329.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The FLT0032-COV is a non-electric reverse osmosis water filtration system with a sealed hydropneumatic storage tank. It produces 175 gpd at 77°F and 60 psi feed water pressure, with production varying by water temperature, pressure, and blended TDS setting.

  • Integrated pre-filtration reduces sediment and chlorine.
  • A mineral-addition cartridge provides TDS needed for conductivity sensors and steam equipment applications.
  • A plumbed-in post-filter reduces chloramine.
  • The system includes hose, tubing, and fittings.

Listed applications include combi ovens, proofers, and steamers.

Product Weight:

24.8 lb

Reverse osmosis water treatment

Produces 175 gpd at 77°F and 60 psi feed water pressure; actual production varies with water temperature, pressure, and blended TDS setting.

Hydropneumatic storage tank

The sealed 5-gallon tank provides pressurized water to downstream equipment.

Mineral addition

An integrated mineral-addition cartridge provides TDS needed for conductivity sensors and optimal mineral content for steam equipment applications.

Integrated pre-filtration

The high-capacity pre-filter reduces sediment and chlorine and protects the membrane from damage.

Post-filtration

A plumbed-in post-filter reduces chloramine.

Non-electric operation

The system operates on available water pressure and requires no electrical connection.

Monitoring and service features

An operating pressure gauge supports visual monitoring of production and pre-filter condition, while an integrated bypass valve helps reduce service interruptions.

Included connections

Hose, tubing, and fittings are included.

Related Searches

Best Sellers Convotherm Equipment New Arrivals Plumbing & Water Treatment Restaurant Equipment Water Filters Water Filtration & Treatment
Daily Production 175 gpd (633 Lpd) at 77°F (25°C) and 60 psi (3.5 bar) feed water pressure
Storage Tank Capacity 5 gallons (18.9 L)
Storage Tank Type Sealed hydropneumatic
Electrical Connection None required
Inlet Connection 3/8" push-fit tubing
Outlet Connection 1/2" I.D. hose
Drain Connection Minimum 2.0 gpm (7.6 Lpm)
Pressure Requirements 60–85 psi (3.5–5.9 bar), non-shock
Inlet Water Temperature 40–100°F (4–38°C)
Feed TDS Up to 1200 ppm
Feed pH 6–10 units
Hardness 12 grains or less
Free Chlorine Less than 2 mg/L
Iron 0.1 mg/L maximum
Turbidity 0.50 NTU
Manganese 0.05 mg/L maximum
Hydrogen Sulfide 0.00 mg/L
Service Flow Rate Dependent on water level and pressure in the storage tank
Processor Dimensions 16.3" H x 12.9" W x 7" D (41.4 cm x 32.7 cm x 17.8 cm)
Post Filter Dimensions 15.4" H x 3.9" W x 3.9" D (39.1 cm x 9.9 cm x 9.9 cm)
Tank Dimensions 20.25" H x 12.25" diameter (51.44 cm x 31.12 cm)
Weight 34 lbs (15.42 kg)
Recommended Cartridge Change Interval Pre-filter, post-filter, and mineral-addition cartridges every six months, when capacity is reached, or when flow becomes too slow
Recommended Membrane Replacement Interval Every 18 months

Documents

PDF Cutsheet PDF Download PDF Installation services & kits PDF Download PDF Installation flyer PDF Download PDF Quotation accuracy checklist PDF Download

Frequently Asked Questions

No. The system has no electrical connection and operates on available water pressure.
The system produces 175 gpd (633 Lpd) at 77°F (25°C) and 60 psi (3.5 bar) feed water pressure. Production varies with water temperature, pressure, and the desired blended TDS setting.
The sealed hydropneumatic storage tank holds 5 gallons (18.9 L).
The system includes pre-filtration for sediment and chlorine reduction, a mineral-addition cartridge, and a post-filter for chloramine reduction.
The specified pressure requirement is 60–85 psi (3.5–5.9 bar), non-shock.
The authoritative product specification lists hose, tubing, and fittings as included.
Pre-filter, post-filter, and mineral-addition cartridges should be changed every six months, when capacity is reached, or when flow becomes too slow. The membrane is recommended for replacement every 18 months.
No. The cutsheet specifies the system for steam generation only and says not to use it for condensate or wash-water.
