Continental Refrigerator BB69SNGDPT Back Bar Coolers
Description
Continental Refrigerator BB69SNGDPT 69" Pass-Thru Back Bar Cooler – Shallow Depth
18 cu. ft. • 4 Hinged Glass Doors • R-290 Natural RefrigerantPerfect for high-volume bars, taprooms and event venues, the low-profile BB69SNGDPT keeps your beverages ice-cold while showing them off from both sides. Its shallow 26-1/4" footprint tucks neatly under standard bar counters, and the front-breathing design eliminates the need for extra clearance behind the unit.
Key Performance Features
- Pass-thru layout with four double-pane, low-E glass doors for easy loading from the back and serving from the front.
- 18 cu. ft. net capacity fits up to 3 half-barrel, 3 straight-wall or 10 sixth-barrel kegs.
- Textured black enamel exterior, stainless steel top and NSF-7 stainless interior back & sides with reinforced floor.
- Front-breathing, slide-out 1/4 HP refrigeration system for quick, tool-free service access.
- Eco-friendly R-290 refrigerant and high-density, CFC-free polyurethane insulation for maximum efficiency.
- Bright LED interior lighting and cylinder keyed locks on every door.
- Electronic controller with large digital display plus hi-/low temperature alarm.
- Automatic hot-gas condensate evaporator—no floor drain required.
Specifications
| Model | BB69SNGDPT |
|---|---|
| Configuration | Shallow-depth pass-thru back bar cooler |
| Net Capacity | 18 cu. ft. (510 L) |
| Door Style / Qty | 4 hinged, tempered glass doors with locks |
| Shelves Supplied | 4 adjustable, epoxy-coated steel |
| Overall Dimensions (W×D×H) | 69" × 26-1/4" × 34-3/4" (1753 × 667 × 883 mm) |
| Body Depth (less doors) | 21" (533 mm) |
| Keg Capacity | 3 half-barrel | 3 straight-wall | 10 sixth-barrel |
| Refrigerant / Compressor | R-290 / 1/4 HP |
| Cooling Capacity | 2,250 BTU/hr (@ +25 °F EV, 90 °F AMB) |
| Electrical | 115 V / 60 Hz / 1-ph, 3.7 A, NEMA 5-15P (10 ft cord) |
| Certifications | cETLus, NSF-7 |
| Shipping Weight | 425 lb (193 kg) |
Included with Your Purchase
- Factory-installed stainless steel countertop
- LED lighting kit
- Four adjustable shelves
- Door locks with two keys
- Pre-wired 10 ft power cord & plug
7-Year Total Coverage Warranty
Continental backs every R-290 model with an industry-leading 7-year parts, labor & compressor warranty when installed and maintained according to the owner’s manual.
Need extra shelves, a wine rack, casters or a riser base? Contact us for factory-approved accessories.
