Connerton LRB-42-F Gas Charbroiler, Floor Model, 42"W, Lava Rock, Cast Iron Grates, Stainless Steel

SKU: LRB-42-F
$7,462.68
/each
Enter ZIP for a shipping estimate

Want to speak to an expert?

The Connerton LRB-42-F is a floor-model gas charbroiler with lava-rock heat, cast iron grates, manual controls, and a 120,000 BTU output.

  • Fully welded #304 stainless steel body and fire box
  • Cast iron top grates with rear height adjustment
  • Cast iron bottom grates over lava rock
  • Stainless steel drip pan, undershelf, and adjustable legs
  • Rear 3/4-inch NPT gas connection

Overall Dimensions:

42.0"W x 27.0"D x 36.0"H

Product Weight:

320.0 lb

Lava-rock heat

Uses lava rock as the heat medium beneath the cast iron bottom grates.

Cast iron grates

Includes cast iron bottom grates and cast iron top grates with rear height adjustment.

Gas output

Provides 120,000 BTU through three 40,000 BTU cast iron burners.

Stainless steel construction

The body and fire box are fully welded #304 stainless steel.

Floor-model stand

Includes an open stand with a stainless steel undershelf and adjustable legs.

Manual controls

Operated with manual controls.

Gas connection

Uses a rear 3/4-inch NPT gas connection.

Stainless steel drip pan

Includes a #304 stainless steel drip pan.

Product type Floor-model gas charbroiler
Heat source Lava rock
Burners 3 cast iron burners
Total output 120,000 BTU
Controls Manual
Top grates Cast iron with rear height adjustment
Bottom grates Cast iron
Gas connection 3/4-inch NPT, rear
Gas pressure 4.0 inches water column natural gas; 11.0 inches water column propane
Body and fire box Fully welded #304 stainless steel
Drip pan #304 stainless steel
Base Open stand
Undershelf Stainless steel
Legs Adjustable

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

Limited warranty for two years from the date of purchase, not exceeding 30 months from shipment; the second year covers parts only.

Frequently Asked Questions

Yes. It is a gas charbroiler with a rear 3/4-inch NPT gas connection.
The charbroiler is rated at 120,000 BTU from three 40,000 BTU burners.
It has lava-rock heat, cast iron bottom grates, and cast iron top grates with rear height adjustment.
The product measures 42 inches wide by 27 inches deep by 36 inches high and weighs 320 pounds.
Yes. It is a floor model with an open stand, stainless steel undershelf, and adjustable legs.
Connerton provides a limited warranty for two years from purchase, not exceeding 30 months from shipment; the second year covers parts only. Broiler grates and radiants are covered for parts only for 90 days.
