Customize Connerton Model no. CN48-2-36G
Connerton CN48-2-36G 48-In Gas Range with 2 Open Burners, 36-In Griddle, Standard Oven and Cabinet
The Connerton CN48-2-36G is a restaurant gas range with two 32,000 BTU open top burners, a 36-inch griddle rated at 18,000 BTU/hr, a standard Bake-n-Roast oven, and a cabinet base.
- Cast iron grates support the open burners.
- The griddle has a 1-inch thick polished steel plate.
- The oven includes one rack with three positions and a full-depth pull-out crumb tray.
- Stainless steel components include the front, sides, riser, and lift-off high shelf.
Overall Dimensions:
48.0"W x 33.9"D x 58.2"HProduct Weight:
640.0 lbOpen burners
Two open top burners provide 32,000 BTU each and use heavy-duty cast iron grates.
36-inch griddle
The griddle uses a 1-inch thick polished steel plate and is rated at 18,000 BTU/hr.
Standard oven
The Bake-n-Roast oven is rated at 35,000 BTU and includes one rack with three positions.
Cabinet base
The base configuration includes one standard oven and one cabinet.
Flash tube pilot
The range uses a flash tube pilot system.
Stainless steel components
The front, sides, riser, and lift-off high shelf are stainless steel.
Adjustable legs
The range has 6-inch stainless steel adjustable legs.
Crumb tray
A full-depth pull-out crumb tray is specified.
Certifications & Compliance
Warranty & Protection
Two-year limited warranty for the original owner of a properly installed commercial unit in a static location; the second year covers parts only.
