Connerton CEG-17-M Countertop Gas Griddle, 17"W x 19" Deep Cooking Surface, 1" Steel Plate, Manual Controls

SKU: CEG-17-M
$2,290.89
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Griddles Commercial Griddles Commercial Grills Connerton Cooking Equipment Equipment Gas Griddles Griddles & Flat Tops New Arrivals Restaurant Equipment

The Connerton CEG-17-M is a countertop gas griddle with manual controls and a 17 in. wide by 19 in. deep cooking surface.

  • Features a 1 in. highly polished steel griddle plate.
  • Constructed with a stainless steel body and stainless steel front panel.
  • Includes a drip pan, fire box, gutter, and 3 in. high splash.
  • Provides 28,000 BTU input through a 3/4 in. NPT rear gas connection.
  • Specified for installation in non-combustible locations.

Overall Dimensions:

17.0"W x 23.0"D x 13.13"H

Product Weight:

100.0 lb

Countertop format

Designed as a countertop gas griddle.

Cooking surface

Provides a 17 in. wide by 19 in. deep cooking surface.

Highly polished steel plate

Uses a 1 in. thick highly polished steel griddle plate.

Manual controls

Equipped with manual controls.

Gas heat

Rated at 28,000 BTU with a U-type tubular burner.

Gas connection

Uses a 3/4 in. NPT rear gas connection.

Stainless steel construction

Features a stainless steel body and stainless steel front panel.

Grease and splash management

Includes a drip pan, gutter, and 3 in. high splash.

Installation requirements

Specified for non-combustible locations with 4 in. side clearance and 6 in. back clearance.

Series Budget Series
Product type Griddle
Mounting style Countertop
Fuel type Gas
Cooking surface width 17 in.
Cooking surface depth 19 in.
Griddle plate thickness 1 in.
Griddle plate finish Highly polished steel
Controls Manual
BTU input 28,000 BTU
Burner type U-type tubular burner
Gas connection 3/4 in. NPT, rear
Gas pressure 5.0 in. water column natural gas; 11.0 in. water column propane
Gas pressure regulator Supplied; must be installed
Body material Stainless steel, fully welded
Front panel material Stainless steel
Drip pan Stainless steel, welded
Fire box Stainless steel, welded
Gutter Stainless steel
Splash height 3 in.
Installation location Non-combustible locations only
Required clearances 4 in. sides; 6 in. back

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

Limited warranty for the original owner: two years from the date of purchase, not to exceed 30 months from the date of shipment; the second year covers parts only.

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The griddle is 17 in. wide, 23 in. deep, and 13.13 in. high.
The cooking surface is 17 in. wide by 19 in. deep and uses a 1 in. highly polished steel plate.
It uses a 3/4 in. NPT rear gas connection and has a 28,000 BTU input.
The CEG-17-M has manual controls.
The unit is specified for non-combustible locations, with 4 in. clearance at the sides and 6 in. clearance at the back.
Connerton provides a limited warranty for the original owner covering properly installed static commercial units for two years from purchase, not exceeding 30 months from shipment. The second year covers parts only.
