Play manufacturer video for Component Hardware Encore D10-7315 Lever Handle Waste Outlet with Overflow, 1-1/2" NPT, 3-1/2" Sink OpeningComponent Hardware Encore D10-7315 Lever Handle Waste Outlet with Overflow, 1-1/2" NPT, 3-1/2" Sink Opening
SKU: D10-7315
$256.40
The Encore D10-7315 is a lever handle waste outlet with an overflow assembly, 1-1/2" NPT outlet, and 3-1/2" sink opening.
- Nickel plated cast brass drain body
- Self-centering stainless steel face flange
- Flat snap-in stainless steel strainer
- Stainless steel lever handle and overflow face plate
- Maximum flow rate of 20 gpm
Product Weight:
6.0 lbLever handle operation
Stainless steel lever handle operates the waste outlet.
Overflow assembly
Includes an overflow head with stainless steel face plate.
Stainless steel face flange
Self-centering face flange supports the sink drain assembly.
Snap-in strainer
Includes a flat snap-in stainless steel strainer.
Cast brass drain body
Drain body is made from nickel plated cast brass.
Maximum flow rate
Rated for a maximum flow rate of 20 gpm.
Type
Lever waste valve
Drain outlet size
1-1/2" NPT
Sink opening
3-1/2"
Maximum flow rate
20 gpm
Drain body material
Nickel plated cast brass
Face flange material
Stainless steel
Handle material
Stainless steel
Strainer material
Stainless steel
Overflow face plate material
Stainless steel
Overflow assembly size
1-1/4"
Flange diameter
4-3/8"
Construction
Solid heavy duty cast body
Approximate shipping weight
6 lb
Warranty & Protection
2-year parts warranty.
Frequently Asked Questions
The D10-7315 is specified for a 3-1/2" sink opening.
The drain outlet size is 1-1/2" NPT.
Yes. It includes an overflow assembly with an overflow head and stainless steel face plate.
The maximum flow rate is 20 gpm.
The drain body is nickel plated cast brass, and the lever handle is stainless steel.
The product has a 2-year parts warranty.
