Cleveland Range KGL40TPQS Quick Ship Steam Kettles
Description
Cleveland “Quick Ship” 40-Gallon Tilting Kettle
Model KGL-40-T – Natural Gas • Manual Tilt • 2/3 Steam JacketNeed big-batch capacity, but can’t wait for a factory lead time? Cleveland’s Quick Ship program puts the legendary Short Series™ KGL-40-T on your loading dock fast, so you can be up and simmering in days instead of weeks. With 140,000 BTU of power, rock-solid 316 & 304 stainless construction, and accuracy within ±1 °C, this 40-gallon tilting kettle is built to crush prep lists and stay on the line for years.
Key Features
- 40 gal / 150 L capacity – ±640 eight-oz servings per batch
- High-efficiency Power Burner system (62 – 65 % thermal efficiency)
- 140,000 BTU natural-gas burner with electronic spark ignition
- 2/3 steam jacket permanently filled with treated distilled water – no venting or refilling
- Solid-state temperature control, 145 – 260 °F (63 – 127 °C) with ±1 °C accuracy
- Manual hand tilt with self-locking worm & gear; field-bolted flanged feet for rock-solid stability
- 316 SS cooking surface, 304 SS exterior, reinforced rolled rim & large pouring lip
- LED heat-cycle & low-water indicators plus front mounted pressure/vacuum gauge
- 50 psi ASME-stamped jacket & safety valve – built for today’s high-speed kitchens
- Factory-wired 120 V, 1-phase, 6 ft cord & plug; CE, CSA, AGA & NSF approvals
Why Operators Love It
- Fast Heat-Up & Recovery – From cold to rolling boil in minutes, keeping production on schedule.
- Consistent Results – Precise temperature control is perfect for delicate sauces and high-volume soups alike.
- Labor-Saving Tilt – Smooth 90° pour reduces lifting injuries and speeds clean-up.
- Future-Proof Construction – 316 stainless interior shrugs off acidic products that destroy lesser kettles.
- Floor-Friendly Footprint – 38″ rim height fits under standard hoods and allows ergonomic stirring.
Technical Specifications
| Capacity | 40 gal (150 L) |
|---|---|
| Steam Jacket Coverage | 2/3 |
| Jacket Pressure Rating | 50 psi (3.4 bar) |
| Heat Input | 140,000 BTU/hr (41 kW) – natural gas |
| Gas Connection | 3/4″ NPT, 4″–14″ W.C. |
| Electrical | 120 V / 60 Hz / 1-ph, 10 A, 6′ cord & plug |
| Tilt Mechanism | Manual hand wheel, worm & segment gear |
| Draw-Off Valve | 2″ tangent draw-off (factory installed); 3″ butterfly & air valves optional |
| Cover | Spring-assisted, hinged stainless cover (optional) |
| Construction | 316 SS interior, 304 SS exterior; insulated heat exchanger |
| Certifications | CE, CSA/AGA, NSF, ASME-code stamped jacket |
| Shipping Weight | ≈ 525 lb (238 kg) |
Popular Factory Accessories
- easyDial™ advanced control panel with timer & core-probe support
- Hot & cold water faucet with swing spout (DPK)
- Food strainer, flow diverter, basket sets & tri-basket supports
- Automatic water meter (gallon or litre)
- Kettle Accessory Kit – paddle, whip, ladle, cleaning brushes & measuring strip
- Propane conversion kit
Warranty & Start-Up
• 1-year parts & labor warranty (18 months from shipment if not installed)
• 4-year prorated steam-jacket parts coverage (years 2-5)
• Free factory-authorized performance start-up and water-quality check upon request
• Kettle must be bolted to the floor and installed under a code-compliant ventilation hood.
• Provide 3″ rear clearance for service access.
• Maintain water quality within Cleveland specifications to preserve warranty.
• Do not locate floor drains directly beneath the unit.
