Cleveland Range 36GMK66300 Steam Kettles
Cleveland Range 36GMK66300 Steam Kettles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Cleveland Range 36GMK66300 Steam Kettles
Description
Cleveland Range 36" Gas Kettle/Cabinet Assembly – Two 6 Gal Kettles, 300,000 BTU Boiler
Model 36-GM-K66-300 | NickelGuard™ Modular BaseBuilt for high-volume kitchens that refuse to compromise on speed, safety or durability, this fully integrated kettle/cabinet system delivers continuous, high-pressure steam from a powerful 300,000 BTU gas boiler to two 6-gallon, 2/3-jacketed kettles. From small-batch sauces to large-scale soups, you’ll get precise temperature control, effortless tilting and the corrosion-resistant performance that only 316 stainless steel interiors can provide.
Why You’ll Love It
- 300,000 BTU Gas-Fired Boiler with NickelGuard™ protection generates ample, consistent steam for simultaneous kettle use.
- (2) 6-Gallon / 23 L Kettles – 2/3 steam-jacketed, 50 psi rating and manual balanced tilt for smooth, splash-free pouring.
- 316 Stainless Steel Liners resist acidic foods far better than 304, extending kettle life and flavor integrity.
- Lift-Off Covers supplied for both kettles to reduce energy loss when cooking in stages.
- Built-In Double Pantry Faucet + Sink & Drain for quick kettle filling and convenient rinse-down between batches.
- Integrated Splash Guard keeps surrounding prep surfaces clean and safe.
- Solid-state Water-Level Controls, Low-Water Cut-Off & 15 psi Safety Valve maintain safe boiler operation at all times.
- Electronic Spark Ignition and illuminated Start/Reset switch for fast, reliable start-ups.
- Automatic Blow-Down & Refill – boiler purges under pressure at shut-down and refills on the next start-up to minimize scaling.
- 430 Stainless Cabinet Base & tabletop with 1.5" drain trough; all major components are front-serviceable.
- Factory-installed Steam Control Kits (needle valves) give each kettle independent steam regulation.
Designed for Busy, Demanding Kitchens
- Produces up to 320 four-ounce servings per cooking cycle (160 per kettle).
- Adjustable flanged feet level the unit on uneven floors and allow secure bolting if required by code.
- Separate pressure gauge and control console keep critical info at eye level.
- Standard 115 V, 60 Hz, 1-phase control circuit – no GFI outlet (hard-wire recommended).
Technical Specifications
| Cabinet Width | 36 in / 900 mm (standard height) |
|---|---|
| Kettle Capacity | (2) × 6 gal / 23 L (each) |
| Jacket Rating | 50 psi (345 kPa) |
| Boiler BTU Input | 300,000 BTU/hr (natural gas) |
| Boiler Operating Pressure | 15 psi safety valve |
| Controls Power | 115 V, 60 Hz, 1-Ph, 25 W |
| Water Supply | 35 – 80 psi (clean, treated water recommended) |
| Drain Connection | 1 in. common drain, boiler blow-down outlet |
| Clearances | Right 6", Left 6", Rear 6" (12" on control side if adjacent equipment is >30" high) |
| Servings per Batch | ≈ 320 × 4 oz portions (total) |
Warranty & Start-Up Support
- 1-Year limited parts & labor on entire assembly.
- Extra 4-Year prorated parts coverage on the pressure boiler section.
- Complimentary performance start-up & water quality check by a Factory Authorized Servicer (U.S. & Hawaii).
Extended warranty options available at time of purchase – ask your sales representative for details.
