Description
Cleveland 24-GM-200 Gas-Fired Steam Generator Cabinet Base
24" wide · 200,000 BTU/h · NickelGuard™ self-draining boilerBuilt for demanding commercial kitchens, the 24-GM-200 delivers a powerful 200 MBTU steam supply in a compact 24" stainless-steel cabinet. Cleveland’s NickelGuard™ technology automatically blows down the boiler at shut-down and refills on start-up, keeping maintenance to a minimum while maximizing uptime. Pair it with kettles, steamers or braising pans—or use it as a stand-alone steam source.
Why you’ll love it
- Heavy-duty 430 stainless steel enclosure, backsplash & table top with attractive #4 finish
- 200,000 BTU/h gas-fired NickelGuard™ steam boiler supplies consistent, high-quality steam
- Automatic blow-down at shut-down & automatic water refill on start-up—no manual draining required
- Solid-state water-level controls + secondary low-water cut-off for fail-safe protection
- Electronic spark ignition eliminates a standing pilot for energy savings & safety
- Front-hinged door and front-serviceable components simplify routine maintenance
- Fully insulated boiler shell reduces heat loss to the work area
- Easy-read pressure gauge and illuminated Start/Reset switches on the control console
- 6" adjustable stainless steel legs with flanged feet for secure, level installation
- Factory-installed gas pressure regulator included
Specifications
| Model | 24-GM-200 |
|---|---|
| Steam output | 200,000 BTU/h (≈58.6 kW) |
| Cabinet width | 24" (610 mm) |
| Depth | 30" (762 mm) |
| Overall height (to top of flue) | 62" (1 575 mm) |
| Gas connection | ¾" NPT – Natural 7" W.C. / Propane 11" W.C. |
| Electrical | 115 V, 60 Hz, 1-ph, 0.5 A (controls only) Hard-wire; do not use GFCI receptacle |
| Water connection | ¾" NPT cold water, 35–80 PSI (2.4–5.5 bar) |
| Drain connection | 1½" IPS common drain (no PVC; do not manifold with other equipment) |
| Safety valve | 15 psi ASME-approved |
| Clearances | 6" right, left & rear; 12" on control side when adjoining other units |
| Construction | Type 430 SS cabinet, backsplash & table top; fully insulated boiler shell |
| Legs | 6" (152 mm) stainless steel, adjustable, flanged |
Total Dissolved Solids 50–250 ppm · Hardness 50–200 ppm (3–12 gpg) · pH 7.0–8.5 · Chloride ≤50 ppm · Free chlorine ≤0.1 ppm · Silica ≤13 ppm · Total alkalinity 50–100 ppm
Warranty
• 1-year parts & labor standard warranty
• Additional 4-year prorated parts coverage on the pressure boiler/steam generator (years 2–5)
Performance start-up by a Factory Authorized Servicer is available at no charge upon request.
