BK Resources  |  SKU: UBB-21-472TS

BK Resources UBB-21-472TS Bar Equipment

$1,774.07
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet
Related Searches
Bar Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

BK Resources 72" 4-Compartment Underbar Sink with Dual Drainboards

Model UBB-21-472TS | NSF Certified 18/304 Stainless Steel

Built for the busiest bar programs, this BK Resources underbar sink combines four generous wash bowls, dual stamped drainboards, and lead-free deck-mount faucets in one rugged, space-saving unit.

Key Features

  • Four integrally welded bowls – 10" W × 14" F-B × 10" D each
  • (2) 13-3/4" stamped & pitched drainboards (left and right)
  • 4-1/2" rear backsplash helps contain splashes and protects walls
  • (2) 4" O.C. deck-mount lead-free faucets included (BKD-10-G)
  • Basket drains (BKDR-2) & removable 7" overflow standpipes (BK-OT-15075) INCLUDED
  • 18-gauge, Type 304 stainless steel bowls, drainboards & apron
  • Removable stainless front panel for simple plumbing access
  • Galvanized pedestal base delivers a sturdy 30" work height (34" overall with backsplash)
  • NSF listed for open food-service use

Specifications

Overall dimensions 72" W × 21-1/4" D × 34" H
Working height 30"
Bowl configuration 4 compartments
Bowl size (each) 10" W × 14" F-B × 10" D
Drainboards (2) 13-3/4" – left & right
Backsplash height 4-1/2"
Faucet centers 4" on-center
Material thickness 18-gauge (0.048")
Stainless type T-304
Included accessories BKD-10-G faucets (2), BKDR-2 basket drains (4), BK-OT-15075 overflow standpipes (4)
Certification NSF

Perfect For

  • High-volume cocktail bars & nightclubs
  • Brewery taprooms & tasting rooms
  • Hotel lounges & banquet facilities
  • Cafés, coffee shops & juice bars
  • Catering or portable event bars (with proper shelter)

Looking to outfit a complete bar line? Matching ice bins, speed rails and glass rinsers from BK Resources are available upon request.

Features & Specs

Manufacturer

BK Resources

Certifications

NSF

Height

21.25in

Width

72.0in

Depth

34.0in

Top Stainless Series

300 series

Construction

stainless steel top, front, ends & legs

Bowl Depth (rim - drain)

10"

Bowl Size

10" x 14" front-to-back

Depth (front - back) OA

20" - 21"

Sink Compartments

(4)

Drainboards

drainboards on left & right

Width (side - side) OA

67" - 72"

Splash

4"

Specifications

Underbar Sink, four compartment, 72”W x 21-1/4"D x 34"H overall size, 10" wide x 14" front-to-back x 10" deep compartments, (2) left & right 13-3/4" stamped drainboards, 4-1/2"H backsplash, (2) 4" OC deck mount lead-free faucets (BKD-10-G), stainless steel apron on front & sides, includes basket drains (BKDR-2) & removable overflow standpipes (BK-OT-15075), 18/304 stainless steel construction, removable stainless steel front panel on galvanized pedestal base, NSF
