Description

Underbar Ice Bin w/ 7-Circuit Cold Plate – 167 lb Capacity

BK Resources | Model UB4-21-IBCP48-7 (NSF)

Keep cocktails flowing and sodas perfectly chilled during the busiest service rush with this heavy-duty underbar ice bin from BK Resources. Built from food-grade 18 ga T-304 stainless steel and equipped with an integrated 7-circuit aluminum cold plate, it delivers rapid, continuous cooling for up to six soda or liquor lines while holding a generous 167 lb of ice.

Why You’ll Love It

  • High-capacity bin: 43" W x 21" D x 12-9/16" H interior stores 167 lb of ice so you never run dry.
  • 7-circuit cold plate: Seamlessly welded aluminum plate chills multiple beverage lines without diluting flavor.
  • Sanitary stainless steel: T-304, 18 ga construction resists corrosion and cleans up in seconds.
  • 4" backsplash: Protects surrounding surfaces from splashes and meets most health-code requirements.
  • Built for bars: Stainless steel legs, side bracing, and adjustable high-impact corrosion-resistant feet ensure rock-solid stability on uneven floors.
  • Ready out of the box: Includes sliding stainless steel lids and factory-installed drain for fast set-up.
  • NSF Listed: Approved for safe food-contact and commercial use.

At-a-Glance Specs

Ice Bin Capacity 167 lb (75.7 kg)
Interior Dimensions 43" W × 21" D × 12-9/16" H (1 092 × 533 × 319 mm)
Cold Plate 7-circuit aluminum (pre-drilled & welded)
Overall Work Height 32 1/2"
Backsplash Height 4"
Material 18 ga T-304 stainless steel (bin, top, lids) / aluminum cold plate
Legs & Bracing Stainless steel with side bracing
Feet Adjustable, high-impact, corrosion-resistant bullet feet
Certification NSF
Manufacturer BK Resources
Heads-up: For beverage service, connect only appropriately insulated beverage lines to the cold plate to prevent condensation and maintain optimal drink quality.

Need a different size, additional circuits, or matching underbar components? Contact us—BK Resources offers a complete lineup of stainless underbar equipment built to the exact same standards.

Features & Specs

Manufacturer

BK Resources

Certifications

NSF

Height

32.5in

Width

48.0in

Depth

21.25in

Shipping Weight

185.0lbs

Construction

stainless steel construction

Cold Plate

(7) circuit

Bin Depth

12" deep ice bin

Depth (front - back) OA

20" - 21"

Width (side - side) OA

43" - 48"

Splash

4"

Ice Capacity

150 - 199 lbs.

Specifications

Underbar Ice Bin, with 7-circuit aluminum cold plate, 167 lbs capacity, 43" wide x 21" front-to-back x 12-9/16" deep ice bin, 4"H backsplash, 18/304 stainless steel construction, stainless steel legs & side bracing, adjustable corrosion resistant feet, NSF
