Description

Extra-Deep Donut Proofing Cabinet – Full-Height, 3-Door

BevLes Model: PICA70-32-AED (Non-Insulated)

Built for high-volume bakeries and donut shops, this mobile proofer delivers precise, uniform temperature and humidity in an extra-deep, full-height footprint that accommodates today’s largest donut screens. Triple clear Lexan® doors give you a full view of every batch without disturbing the proofing environment.

Why You’ll Love It

  • Accepts up to 16 full 23" × 32" donut screens—or a wide mix of trays and pans.
  • Three clear Lexan® split doors (right-hand hinged) for easy, energy-saving access.
  • Digital thermostat (60°–120 °F) with variable humidity dial and bright LED display.
  • 5 qt cast-aluminum water reservoir with “cast-in” element guards against burnout.
  • Adjustable extruded aluminum pan supports on 1-1/2" centers.
  • Removable bottom-mounted heat/humidity module for fast cleaning & service.
  • .063" formed aluminum body; full-perimeter door gaskets lock in heat and moisture.
  • 5" swivel plate casters, two locking, let you roll the cabinet anywhere it’s needed.
  • cULus & NSF listed for electrical safety and sanitation.

Pan / Screen Capacity

  • (16) 23" × 32" donut screens
  • (16) 23" × 23" donut screens
  • (16) 18" × 26" sheet pans
  • (32) 12" × 20" steam-table pans

Technical Specifications

Exterior dimensions (W × D × H) 29" × 39" × 71.5" (740 × 991 × 1820 mm)
Interior height 57" (1450 mm)
Temperature range 60°–120 °F (15.6°–48.9 °C)
Humidity control Variable, independent of heat
Doors (3) clear Lexan® split doors, right-hand hinged, positive-latch
Water reservoir 5 qt (4.7 L) cast aluminum with cover
Electrical 208-230 V / 50-60 Hz / 1-phase, 1400 W, 7.5/6.8 A, cord only (no plug)
Casters 5" swivel plate (front two brakes)
Construction Non-insulated .063" aluminum body & .125" base
Certifications cULus, NSF
Shipping weight Approx. 290 lb (132 kg)

Popular Options & Accessories (sold separately)

  • Reverse door hinging or solid doors
  • Corner or perimeter non-marking bumpers
  • 6" casters with soft-rubber wheels
  • 6" stainless-steel legs for stationary installation
  • Extra pan supports & 18" × 26" wire racks
Important: Always fill the water reservoir before energizing the cabinet. Operating without water may damage the humidity system and is not covered by warranty.

Specifications are subject to change without notice. Pans and screens shown in photos are not included.

Features & Specs

Manufacturer

BevLes Company

Certifications

NSF, cULus

Height

71.5in

Width

29.0in

Depth

39.0in

Shipping Weight

290.0lbs

Exterior Finish

all aluminum exterior

Heater

bottom mounted heater

Full Size Sheet Pan Capacity

(16) 18" x 26" pans

Slide Centers

adjustable centers on 1-1/2"

Full Size Hotel Pan Capacity

(32) 12" x 20" pans

Interior Finish

aluminum interior

Insulation

non-insulated

Sections

1 section w/1 compartment

Specifications

Extra Deep Proofing Cabinet (donut proofer), mobile, full height, non-insulated, (3) clear Lexan® right-hand hinged split doors, digital thermostat, variable humidity control & LED display, 60° to 120°F temperature range, adjustable aluminum pan supports on 1-1/2" centers accommodate (16) 23" x 32" donut screens, or (16) 23" x 23" donut screens, (16) 18" x 26" trays, or (32) 12" x 20" pans, removable heating module, 5 qt. cast water reservoir with cover, 5" swivel plate casters (2 with brakes), aluminum construction, 208-230v/50/60/1-ph, 1400 watts, 7.5/6.8 amps, cord only, cULus, NSF
