BevLes Company  |  SKU: PICA60-24INS-A-4R1

BevLes Company PICA60-24INS-A-4R1 Dough Proofers & Retarders

$4,567.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Freight guidelines Freight guidelines Brochure Warranty sheet
Related Searches
Food Holding & Warming Equipment Food Warmers & Holding Equipment Holding Cabinets Holding Cabinets Proofing Cabinets Proofing Cabinets Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

BevLes Insulated Mobile Donut Proofer – 3/4 Height

Model PICA32-10INS-A | 208-230 V Single-Phase

Give every batch the perfect rise. This 3/4-height BevLes proofer pairs tight temperature control with adjustable humidity, all inside a fully-insulated aluminum cabinet that rolls wherever your production line needs it.

Key Features

  • Fully insulated top, back & sides for dependable heat retention and energy efficiency.
  • Digital thermostat with LED read-out plus independent humidity dial; 60 – 120 °F (16 – 49 °C) range.
  • 5 qt (4.7 L) cast-aluminum water reservoir with “cast-in” element—prevents burnout and splashing.
  • Universal aluminum pan supports on 1 ½" centers hold:
    • (12) 18" × 26" sheet pans
    • (24) 12" × 20" steam-table pans
    • (12) 23" × 23" donut screens
  • Clear Lexan® right-hand hinged door with perimeter gasket and positive-action latch for quick visual checks.
  • Removable bottom-mounted heating module for fast, tool-free cleaning.
  • (4) 5" swivel plate casters—front two lock for rock-solid loading and unloading.
  • cULus & NSF listed for commercial compliance.

Perfect For

  • Donut and bagel operations
  • Artisan bread or roll production
  • Cafés, commissaries & ghost kitchens needing a compact mobile proofer

Specifications

Exterior Dimensions (W × D × H) 29" × 33.5" × 57.5" (740 × 850 × 1460 mm)
Pan / Screen Capacity (12) 18" × 26" | (24) 12" × 20" | (12) 23" × 23"
Pan Spacing Adjustable on 1.5" centers
Temperature Range 60 – 120 °F (16 – 49 °C)
Humidity Control Variable, front-panel dial
Electrical 208-230 V / 50-60 Hz / 1-Ph, 1400 W, 7.5 A @208 V (cord only)
Construction .063" formed aluminum body, .125" base, insulated top/sides/back
Door Clear Lexan®, right-hand hinge, full perimeter gasket
Water Reservoir 5 qt cast aluminum with cover
Casters (4) 5" swivel plate (2 with brakes)
Certifications cULus, NSF
Shipping Weight ≈ 190 lb (86 kg)

Need alternate voltage, door swing or extra pan supports? Contact us for factory-installed options and accessories.

Features & Specs

Manufacturer

BevLes Company

Certifications

NSF, cULus

Height

56.5in

Width

29.0in

Depth

33.5in

Shipping Weight

260.0lbs

Heater

bottom mounted heater

Doors

full height doors, plastic

Interior Finish

aluminum interior

Full Size Sheet Pan Capacity

(12) 18" x 26" pans

Sections

1 section w/1 compartment

Exterior Finish

all aluminum exterior

Slide Centers

adjustable centers on 1-1/2"

Insulation

insulated

Full Size Hotel Pan Capacity

(24) 12" x 20" pans

Specifications

Proofing Cabinet (donut proofer), mobile, 3/4 height, insulated top, back & sides, (1) clear Lexan® right-hand hinged door, digital thermostat, variable humidity control & LED display, 60° to 120°F temperature range, adjustable aluminum pan supports on 1-1/2" centers accommodate (12) 18" x 26" or (24) 12" x 20" pans, or (12) 23" x 23" donut screens, removable heating module, 5 qt. cast water reservoir with cover, 5" swivel plate casters (2 with brakes), aluminum construction, 208-230v/50/60/1-ph, 1400 watts, 7.5/6.8 amps, cord only, cULus, NSF
