Beverage-Air Two-Section 48-Inch Shallow-Depth Pass-Thru Back Bar Refrigerator with 4 Solid Doors

SKU: BBN48HC-PT-S
$7,115.72
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Back Bar Coolers Back Bar Coolers Bar Equipment Bar Refrigeration Bar, Beverage & Wine Cooling Best Sellers Beverage Air Commercial Refrigeration Commercial Refrigerators New Arrivals Refrigeration, Freezing & Ice Restaurant Equipment

Beverage-Air Two-Section 48-Inch Shallow-Depth Pass-Thru Back Bar Refrigerator with 4 Solid Doors

Stainless Steel, Self-Contained R290, 12.56 Cu. Ft.

Keep bar service moving from both sides with a shallow-depth pass-thru refrigerator that combines locking solid doors, efficient R290 cooling, and a durable stainless steel build.

  • Pass-thru design allows loading from one side and service from the other for faster bar workflow.
  • Four solid, self-closing doors with locks and magnetic gaskets help protect product and hold temperature.
  • 12.56 cu. ft. capacity stores up to two 1/2-barrel kegs plus shelf storage.
  • Stainless steel exterior, 1" stainless top, and stainless steel floor deliver long-lasting durability.
  • Self-contained R290 refrigeration with full electronic control maintains a 36°F to 38°F holding range.
  • LED interior lighting and four epoxy-coated shelves improve visibility and organization.

Overall Dimensions:

48.0"W x 30.13"D x 34.0"H

Product Weight:

320.17 lb

Pass-Thru Access

Doors on both sides make loading and service faster in busy bar environments.

Locking Solid Doors

Four solid doors are self-closing, include a 120° stay-open feature, and use magnetic gaskets for a tight seal.

Durable Stainless Construction

Built with a stainless steel exterior, 1" stainless steel top, galvanized steel interior walls and ceiling, and a stainless steel floor.

Efficient Refrigeration Control

Full electronic control, adaptive defrost, and balanced forced-air refrigeration help maintain 36°F to 38°F.

Bright, Organized Interior

LED lighting and four epoxy-coated wire shelves make stored products easier to see and arrange.

Keg-Friendly Capacity

12.56 cu. ft. of storage accommodates up to two 1/2-barrel kegs.

Standard Height Design

The 34-inch cabinet height supports standard floor-mount applications and ADA-height use cases.

Type Back Bar Refrigerator
Style Pass-Thru
Installation Type Floor Model
Compartments 2
Capacity 12.56 Cubic Feet
Controls Electronic
Temperature Range 36°F to 38°F
Material Stainless Steel
Interior Finish Galvanized Steel
Finish Stainless Steel
Refrigeration Type Self-Contained
Refrigerant Type R290 Hydrocarbon
BTU 1,942 BTU/Hr
Voltage 115 Volts
Amps 3.3 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Selling Unit Each
Units Per Case 1
Shipping Width 50 3/4 Inches
Shipping Depth 36 1/2 Inches
Shipping Height 42 3/16 Inches
Shipping Weight 320 lb.

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

7-year parts and labor warranty; 7-year compressor part coverage for eligible units.

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It has 12.56 cu. ft. of capacity and can hold up to two 1/2-barrel kegs.
It is wired for 115/60/1 power, draws 3.3 full load amps, and includes a NEMA 5-15P plug with an 8-foot cord.
It includes four solid doors with locks and four epoxy-coated wire shelves.
It uses R290 hydrocarbon refrigerant with a balanced forced-air refrigeration system.
The crated unit ships at 50 3/4"W x 36 1/2"D x 42 3/16"H and weighs 320 lb.
It carries a 7-year parts and labor warranty, plus 7-year compressor part coverage for eligible units shipped after 07/01/2024.
