Beverage-Air BBN48HC-F-PT-B Two-Section Pass-Thru Open Food-Rated Back Bar Refrigerator, 48-Inch, 4 Solid Doors

Shallow Depth, Self-Contained R290 Refrigeration, Stainless Steel Top

Built for busy bars and foodservice displays, this shallow-depth pass-thru refrigerator combines open-food certification, durable construction, and efficient self-contained cooling in a compact 48-inch footprint.

  • Pass-thru design with four solid doors for access from either side.
  • NSF Standard 7 open food rated for displayed or packaged food.
  • 12.56 cu. ft. capacity with four epoxy-coated shelves and space for two half-barrel kegs.
  • Self-contained R290 refrigeration with electronic controls and a 36°F to 38°F holding range.
  • Black painted steel exterior, stainless steel interior, and 1-inch stainless steel top.
  • Standard 34-inch height is ADA compliant and includes LED lighting, door locks, and magnetic gaskets.

Overall Dimensions:

48.0"W x 30.13"D x 34.0"H

Product Weight:

320.17 lb

Pass-Thru Access

Doors on both sides simplify loading, service, and high-volume bar operation.

Open Food Rated

Certified for open food product and meets NSF Standard 7 requirements for open food containers.

Cabinet Construction

Durable black painted steel exterior, stainless steel interior, galvanized sub top, and a 1-inch stainless steel top.

Flexible Storage

Includes four epoxy-coated wire shelves and space for two half-barrel kegs.

Refrigeration System

Balanced forced-air, self-contained R290 refrigeration supports rapid chilling and efficient operation.

Door Package

Self-closing solid doors include a 120° stay-open feature, locks, and magnetic gaskets for a tight seal.

Controls and Lighting

Full electronic control and LED interior lighting help maintain and display product effectively.

ADA Height

Standard 34-inch height supports ADA-compliant installation.

Type Back Bar Refrigerator
Style Pass-Thru
Installation Type Floor Model
Capacity 12.56 Cu. Ft.
Temperature Range 36°F to 38°F
Number Of Sections 2
Number Of Doors 4
Number Of Shelves 4
Voltage 115 Volts
Amps 3.3 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 8 Feet
BTU 1942 BTU/Hr
Refrigeration Type Self-Contained
Refrigerant Type R290 Hydrocarbon
Color Black
Finish Black Painted Steel
Interior Finish Stainless Steel
Selling Unit Each
Units Per Case 1
Shipping Width 50 3/4 Inches
Shipping Depth 36 1/2 Inches
Shipping Height 42 3/16 Inches
Shipping Weight 320 lb.

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

7-year parts, labor, and compressor warranty.

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It has doors on both sides, allowing access from either side for easier loading and service.
Yes. It is certified for open food product and meets NSF Standard 7 for open food containers.
It operates on 115/60/1 power, draws 3.3 amps, and uses a NEMA 5-15P plug.
The unit maintains a holding range of 36°F to 38°F.
It includes a 7-year parts, labor, and compressor warranty.
Yes. A right-side compressor location option (-ALT) is available, and height options include 34 inches standard floor mount, 37 inches with 3-inch casters, or 40 inches with 6-inch casters.
