The Belshaw MARK V INSIDER CABINET is an Insider cabinet with an integrated hood and fire suppression system for Mark V.

Its air-recycling ventilation assembly uses a fan-assisted grease filter, electrostatic filter, and carbon odor filters. A ventilation interlock ensures ventilation is active when the fryer is on. Clear hinged/sliding viewing windows provide access and cleaning, and heavy-duty 5-inch casters are specified.

The cabinet uses a single power connection rated at 208–240 V, 50–60 Hz, single phase, 50 A, with a NEMA #14-50 plug.

Overall Dimensions:

114.0"W x 31.0"D x 91.5"H

Product Weight:

1444.0 lb

Integrated hood and fire suppression

Includes an integrated ventilation hood and fire suppression system for Mark V.

Air-recycling ventilation

Uses a fan-assisted grease filter, electrostatic filter, and carbon odor filters.

Ventilation interlock

Ensures ventilation is active when the fryer is on.

Viewing windows

Clear hinged/sliding windows provide access and cleaning.

Heavy-duty casters

Specified with 5-inch casters.

Electrical connection

Uses a single power connection with a NEMA #14-50 plug.

Application Mark V
Ventilation system Air recycling system
Grease filtration Fan-assisted grease filter
Electrostatic filtration Electrostatic filter
Odor filtration Carbon odor filters
Fire suppression system Pyro-Chem Kitchen Knight II, PLC-240/300
Ventilation interlock Ensures ventilation is active when fryer is on
Viewing windows Clear, hinged/sliding
Caster size 5 in
Electrical connection Single power connection
Voltage 208–240 V
Frequency 50–60 Hz
Phase 1 ph
Current 50 A
Plug NEMA #14-50

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

One-year limited warranty from the date of shipment to the original purchaser.

Documents

PDF Cutsheet PDF Download PDF Warranty PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It is an Insider cabinet with an integrated hood and fire suppression system for Mark V.
The specified electrical requirement is 208–240 V, 50–60 Hz, single phase, 50 A, with a single power connection and NEMA #14-50 plug.
The air-recycling system includes a fan-assisted grease filter, electrostatic filter, and carbon odor filters.
The listed clearances are 36 in at the rear, 36 in at the left side when viewed from the rear, and 18 in overhead for air discharge.
The Insider is described as requiring no exterior ductwork because it has an integrated ventilation hood.
