Belshaw

Belshaw 618L-624-634 Electric Fryers 634 OPEN KETTLE FRYERS Electric Floor-Model Donut Fryer, Open Kettle, Stainless Steel, 197-lb Capacity

SKU: 634 OPEN KETTLE FRYERS
$14,840.64
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Belshaw Best Sellers Butane Stove Commercial Fryers Cooking Equipment Cooking Equipment Cooking Equipment Countertop Cooking Equipment Donut Fryers Equipment Fryers New Arrivals Restaurant Equipment

The Belshaw 634 is an electric, floor-model open kettle donut fryer designed for cake and yeast-raised donuts. It has a 34 x 24 in frying area and 197 lb fat capacity.

The fryer features electronic temperature control, stainless steel construction, tilt-up elements, an exterior drain valve control, and adjustable bolt-down legs.

  • Temperature control: Electronic controller displays current and set temperature.
  • Construction: Stainless steel tank, cabinet, and drain tray.
  • Frying equipment: Two frying screens with bolt-on handles.
  • Electrical: 208-240 V, 50/60 Hz, 3-phase service; electrical cord and plug are not supplied.

Overall Dimensions:

40.5"W x 36.0"D x 40.0"H

Product Weight:

385.0 lb

Open kettle electric design

Floor-model fryer designed for cake and yeast-raised donuts.

Electronic temperature control

The controller displays current and set temperature and keeps temperature within a narrow band.

Stainless steel construction

The tank, cabinet, and drain tray are stainless steel.

Tilt-up elements

Elements tilt upward to allow quicker kettle cleanup.

Frying screens

Two frying screens are specified with bolt-on, heat-dissipating handles.

Exterior drain control

Heavy-duty drain and valve are controlled by an exterior handle.

Reversible drain tray

The drain tray is field reversible to either side.

Adjustable bolt-down legs

Adjustable legs provide a bolt-down installation configuration.

High-temperature limit switch

A high-temperature limit switch is included.

Type Electric
Configuration Open kettle, floor model
Frying area 34 x 24 in
Screen size 33 x 23 in
Fat capacity 197 lb; approximately 26.5 gal (100 L) shortening capacity
Production capacity Up to 120 dozen/hour at 120-second fry time with a standard 3.5 in donut
Temperature control Electronic
Construction Stainless steel tank, cabinet, and drain tray
Screen count 2 frying screens
Drain control Exterior valve control
Drain tray Field reversible either side
Legs Adjustable, bolt-down
Electrical 208-240 V, 50/60 Hz, 3-phase
Electrical cord and plug Not supplied
Weight 385 lb

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed
Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

One-year limited warranty from the date of shipment to the original purchaser.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The frying area is 34 x 24 in.
The specified fat capacity is 197 lb. The cutsheet also lists approximately 26.5 gal (100 L) of shortening capacity.
It requires 208-240 V, 50/60 Hz, 3-phase electrical service.
The specifications list two frying screens with bolt-on handles.
The product measures 40.5 in wide x 36 in deep x 40 in high.
No. The cutsheet states that the electrical cord and plug are not supplied.
It uses an electronic temperature controller that displays current and set temperature.
The manufacturer’s limited warranty extends for one year from the date of shipment to the original purchaser, subject to its terms and exclusions.
