Bakers Pride (Middleby) ER-3-12-5736 Super Deck Series Deck Ovens
Description
Super Deck Series Triple-Deck Electric Bake/Roast Oven
Model ER-3-12-5736 | Bakers Pride® (a Middleby brand)Built for high-volume kitchens that refuse to compromise on bake quality, the Super Deck ER-3-12-5736 combines the legendary Bakers Pride deck-oven heritage with the low-maintenance advantages of an all-electric platform. Three spacious 57" × 36" steel decks give you 46 ft² of baking surface—enough room for pizza, flatbreads, roasted proteins, sheet-pan entrées, and more—all while delivering the even, balanced heat customers expect.
Why You’ll Love It
- Triple-deck design = triple the output in the same footprint
- 12" deck height fits full sheet pans, deep roasting pans, or stacked pizza screens
- Independent U-shaped elements above & below each deck for precise top/bottom balance
- Infinite heat controls (140 – 550 °F / 60 – 288 °C) for baking, roasting, or finishing
- Full-width, spring-balanced doors stay cool and stay put
- Fully welded angle-iron frame—built to withstand daily pounding and allow safe stacking
- All-stainless exterior & aluminized-steel interior for easy cleanup and long service life
- 60-minute timer per deck keeps every batch on schedule
- NSF, UL, and CSA listed
Specifications
| Deck cavities | 3 (stacked) |
|---|---|
| Interior deck size (W × D) | 57" × 36" (1448 × 914 mm) each |
| Usable deck height | 12" (305 mm) |
| Temperature range | 140 – 550 °F (60 – 288 °C) |
| Heating elements | Top & bottom U-shaped elements every 9 ½" |
| Total power | 36 kW (12 kW per deck) |
| Electrical options | 208, 220/240 V; 1- or 3-phase (see amp draw below) |
| 3-phase amps (L1/L2/L3) | 208 V 39/39/39 A | 240 V 35/35/35 A |
| 1-phase amps | 208 V 58 A | 240 V 52 A (per deck) |
| Exterior dimensions (W × D × H) | 74" × 43" × 72" (1880 × 1092 × 1829 mm) incl. 6" legs |
| Shipping weight | Approx. 2100 lb (953 kg) – ships in 4 cartons (3 oven sections + legs) |
| Warranty | 1-year parts & labor, factory-authorized service network |
Included & Optional Accessories
- Standard 6" Bakertone-finished steel legs
- 48" deck brush/scraper (optional)
- Heavy-duty flame diverters (one per deck)
- 5-hour timer upgrade
- Caster kit or special-height legs
- Cordierite or Lightstone decks in place of steel
- Stainless steel wood-chip box for smoky flavor profiles
Financing Made Easy
Preserve capital and get the oven you need now. Fixed monthly payments, fast credit decisions, and potential Section 179 tax advantages are available through Middleby Equipment Financing.
Need a different configuration? Single and double decks, side-mounted controls, and additional voltages are available—contact us for a custom quote.
