Atosa CB3T011 Tall Single Automatic-Fill Coffee and Tea Brewer, Stainless Steel, 1.5-Gallon Capacity

SKU: CB3T011
$1,419.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Atosa CB3T011 is a tall, single automatic-fill coffee and tea brewer with a 1.5-gallon (5.68 L) capacity.

  • Brews up to 160 cups (12 gallons) of coffee or tea per hour.
  • Uses sprayhead technology, pre-infusion, and pulse brew for programmable brewing.
  • Includes a 5-inch color touchscreen with digital controls, USB programming, an energy-saver mode, and a brew counter.
  • Features a stainless steel body and hot water dispenser.
  • Supports standard 1–1.5-gallon and larger coffee servers or tea dispensers.
  • Field-adjustable for 120 V or 208–240 V operation.

Overall Dimensions:

14.62"W x 26.0"D x 38.62"H

Product Weight:

25.0 lb

Programmable touchscreen controls

A 5-inch color touchscreen provides programmable brewing and digital controls.

Brewing functions

Sprayhead technology, pre-infusion, pulse brew, programmable brew recipes, USB programming, energy-saver mode, and a brew counter are supported.

Field-adjustable voltage

The brewer is field-adjustable for 120 V or 208–240 V operation.

Hot water dispenser

The single brewer includes a hot water dispenser.

Water connection

The unit uses a 3/4-inch MNPT water inlet and includes a 3/8-inch O.D. Push-To-Connect x 3/4-inch FNPT connector with 3/8-inch O.D. tubing.

Server compatibility

Supports standard 1–1.5-gallon and larger coffee servers or tea dispensers.

Stainless steel body

The body is stainless steel.

Related Searches

Airpot Coffee Makers Atosa Best Sellers Beverage Equipment Beverage Equipment Beverage Equipment Coffee Brewers Commercial Coffee Brewers Commercial Coffee Makers Equipment Ice Machines & Beverage Equipment New Arrivals Restaurant Equipment
Product type Coffee and tea brewer
Configuration Tall, single
Fill type Automatic fill
Capacity 1.5 gal / 5.68 L
Brew capacity Up to 160 cups (12 gal) per hour
Body material Stainless steel
Controls 5-inch color touchscreen with programmable brewing and digital controls
Brew functions Sprayhead technology, pre-infusion, pulse brew, energy-saver mode, brew counter, programmable brew recipes, and USB programming
Hot water dispenser Included
Server compatibility Standard 1–1.5-gallon and larger coffee servers or tea dispensers
Water inlet 3/4-inch MNPT
Water pressure 7.3–87 psi
Water flow rate 0.05–0.6 MPa
Water inlet connector 3/8-inch O.D. Push-To-Connect x 3/4-inch FNPT connector with 3/8-inch O.D. tubing
Power 1440 W / 2180–2880 W
Voltage Field-adjustable 120 / 208–240 V
Frequency 60 Hz
Phase 1 phase
Amperage 12 A / 10.4–12 A
Plug type NEMA 5-15P standard / NEMA L14-20 optional

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Warranty & Protection

1-year parts and labor warranty.

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The brewer has a 1.5-gallon (5.68 L) capacity.
It can brew up to 160 cups, or 12 gallons, of coffee or tea per hour.
It is field-adjustable for 120 V or 208–240 V, 60 Hz, single-phase operation. Power is 1440 W or 2180–2880 W, with 12 A or 10.4–12 A depending on the configuration.
The NEMA 5-15P is standard and the NEMA L14-20 is optional.
The brewer uses a 3/4-inch MNPT water inlet, with specified water pressure of 7.3–87 psi and water flow rate of 0.05–0.6 MPa.
Yes. It includes a 3/8-inch O.D. Push-To-Connect x 3/4-inch FNPT water inlet connector and 3/8-inch O.D. tubing.
The product has a 1-year parts and labor warranty.
