Atlas Metal Remote Refrigerated 5-Pan Full-Size Deep Cold Food Drop-In Unit with Side Coils
Atlas Metal Remote Refrigerated 5-Pan Full-Size Deep Cold Food Drop-In Unit with Side Coils
No Compressor Included; 304 Stainless Steel Top and Inner Liner, Galvanized Steel Outer Case
Built for remote refrigeration, this deep drop-in cold pan keeps five full-size pans chilled with durable stainless construction and no onboard compressor.
- Remote refrigeration design keeps the compressor off the unit and requires a separate solenoid package.
- Holds five full-size 12" x 20" pans and accepts fractional pans with optional adapter bars.
- Deep design accommodates inserts up to 9-3/4" deep for generous cold storage.
- 304 stainless steel top and one-piece inner liner deliver sanitary, durable food-contact surfaces.
- Fully insulated with high-density polystyrene and a galvanized steel outer case for better temperature retention.
- Copper tubing around the bottom and all sides promotes even refrigeration coverage.
- Factory gasket and raised beaded top help seal the unit to the countertop and reduce seepage.
Product Weight:
202.0 lbRemote Refrigeration Configuration
Designed for a remote condensing system; the compressor is not included with the unit.
Five-Pan Full-Size Capacity
Accommodates standard 12" x 20" pans with separator channels, and fractional pans can be used with optional adapter bars.
Deep Insert Capacity
Built to accept deeper inserts up to 9-3/4" for added food storage capacity.
304 Stainless Steel Top
18-gauge type 304 stainless steel top with a raised perimeter bead for durability and countertop sealing.
304 Stainless Steel Inner Liner
One-piece, welded inner liner with coved corners for a sanitary, easy-to-clean interior.
Copper Refrigeration Tubing
Copper tubing is soldered to the exterior bottom and all sides for even cooling.
High-Density Insulation
Fully insulated with polystyrene on the sides and bottom to improve efficiency and temperature retention.
Galvanized Steel Outer Case
22-gauge galvanized steel outer case provides a rugged exterior enclosure.
Integrated Drain Assembly
Includes a 3/4" drain with strainer, 4" PVC nipple, and valve.
Countertop Gasket Seal
A solid vinyl gasket under the beaded edge helps seal the unit to the counter and prevent seepage or marring.
Warranty & Protection
1-Year Parts & Labor
