Atlas Metal RM-HP-1 Dual Temperature 1-Pan Drop-In Food Well

Single Pan, Dual Temperature, Self-Contained Refrigeration

Experience ultimate serving flexibility with the Atlas Metal RM-HP-1, a versatile drop-in unit offering both hot and cold food holding capabilities in a single pan.

  • Seamlessly switch between hot or cold food holding with a single selector switch.
  • Designed to accommodate one standard 12" x 20" full-size pan.
  • Features durable 18 gauge, type 304 stainless steel construction for long-lasting commercial use.
  • Equipped with self-contained refrigeration and an immersion heating element for reliable performance.
  • Fully insulated design ensures maximum efficiency and significant energy savings.
  • Easy drop-in installation with a factory-applied vinyl gasket to seal to your counter.
  • UL Listed and NSF Certified, ensuring compliance with commercial safety and sanitation standards.

Overall Dimensions:

18.13"W x 26.0"D x 27.75"H

Product Weight:

145.0 lb

Dual Temperature Operation

Functions as a hot serving unit or a refrigerated cold pan with the flip of a selector switch, providing maximum versatility for your menu.

Dual Temperature Operation

Efficient Insulation

The pan is fully insulated with high-density fiberglass, 1-3/8" thick on all sides and 1-1/2" thick on the bottom, maximizing efficiency and promoting energy savings.

Factory Applied Gasket

A solid vinyl gasket is factory-applied under the beaded edge, simplifying installation and ensuring a complete seal to the counter top to prevent seepage.

Standard Pan Capacity

Accommodates one standard 12" x 20" pan with the use of removable separator channels and pan rails, or fractional size pans with optional adapter bars.

Immersion Heating Element

An immersion-type heating element is provided in the bottom of the pan, protected by a perforated stainless steel sheath cover, ensuring even and efficient heating when in hot mode. Requires water to operate properly.

Self-Contained Refrigeration System

Features a fully self-contained condensing unit with a hermetically sealed compressor and thermostat control, pre-charged with CFC-free refrigerant and ready for operation.

Durable Stainless Steel Construction

The top and inner liner are constructed from 18 gauge, type 304 stainless steel, die-stamped with coved corners for easy cleaning and a uniform finish.

Galvanized Steel Outer Case

The insulated pan is enclosed with a robust 22 gauge galvanized steel outer case for enhanced durability.

User-Friendly Controls

Equipped with a hot/cold selector switch, individual thermostat controls for both heating and cooling, and a pilot light to indicate operational status.

Integrated Drain System

Includes a 3/4" diameter drain with a strainer, 4" copper nipple, and a valve for convenient and effective drainage.

Type Hot/Cold Food Drop-In Unit
Style Dual Temperature Food Well
Installation Type Drop-In
Pan Capacity 1 Full-Size Pan
Controls Hot/Cold Selector with Thermostats
Interior Finish 304 Stainless Steel
Material Stainless Steel
Capacity 12" x 20" Pan
Refrigeration Type Self-Contained
Refrigerant Type CFC-Free
Drain Connection Size 3/4 Inch
Drain Connection Required
Voltage 120 Volts
Watts 2000 Watts (Heating Element)
Hertz 60 Hz
Phase 1-Phase
Cord Length 6 Feet
Shipping Width 19 Inches
Shipping Depth 26 Inches
Shipping Height 28 Inches
Shipping Weight 145 lb.
Selling Unit Each
Units Per Case 1
Country of Origin USA

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Warranty & Protection

1-year parts and labor

Documents

PDF Cutsheet PDF Download PDF Parts list PDF Download PDF Troubleshooting PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

The Atlas Metal RM-HP-1 requires a counter cut-out opening of 16-1/2"W x 24-1/2"D for proper installation.
Yes, water must be used in the unit for the hot mode. The immersion heating element must be completely submerged in water to operate properly and prevent damage. It is recommended to check the water level before operation and approximately every 4 hours of continuous use.
To switch from hot to cold, first turn the master switch to 'OFF', remove serving pans, and completely drain the hot water. Then, turn the selector switch to 'COLD' and the master switch to 'ON'. Note that the cold cycle will not energize until the stainless liner temperature is at 120 degrees Fahrenheit or below.
Regular maintenance includes cleaning the condenser coil regularly and periodically cleaning the heater sheath of lime or other built-up material to prevent overheating. When cleaning the pans, avoid chloride-based products, steel wool, or abrasive materials, as they can cause damage. Use soapy warm water and rinse thoroughly.
The RM-HP-1 utilizes a 1/5 HP hermetically sealed compressor as part of its self-contained refrigeration system, which is fully charged with CFC-free refrigerant.
The Atlas Metal RM-HP-1 comes with a 1-year parts and labor warranty. An optional 5-year compressor warranty (model 5YW) is available as an accessory.
