Arcobaleno Pasta Equipment AEX90M Floor-Model Pasta Extruder with Double Mixer, Stainless Steel, Automatic Cutting Knife

SKU: AEX90M
$25,719.12
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Arcobaleno Pasta Equipment Best Sellers Commercial Pasta Machines Commercial Pasta Machines Dough Mixer Accessories Dough Preparation Equipment Equipment Food Prep Equipment Food Preparation Equipment New Arrivals Restaurant Equipment

AEX90M is an industrial floor-model pasta extruder with a double mixer for continuous production. It combines mixing and extrusion in one process and produces up to 110 lb/hr, with output varying by pasta shape and recipe.

Water cooling with a digital temperature readout helps maintain extrusion temperature. Touchscreen control provides preset pasta-shape recipes, variable mixing and extruding speeds, different cutting speeds, and alarms for errors and emergency-button activation.

  • Includes an automatic cutting knife for short pasta shapes, one solid tray, one perforated tray, and two standard pasta dies.
  • Stainless steel construction with a removable auger and stainless steel mixing arm.
  • Pre-plumbed water in and water out lines and four casters.

Overall Dimensions:

26.5"W x 45.0"D x 63.5"H

Product Weight:

535.0 lb

Double mixer

The machine is equipped with a double mixer for continuous production.

Automatic cutting knife

Includes an automatic cutting knife for short pasta shapes.

Touchscreen control

Provides preset pasta-shape recipes, variable mixing and extruding speeds, different cutting speeds, and alarms.

Water cooling

Water cooling with a digital temperature readout helps maintain extrusion temperature.

Removable auger

The auger is removable for cleaning.

Stainless steel construction

The machine includes stainless steel construction and a stainless steel mixing arm.

Four casters

The machine is mounted on four casters.

Included trays and dies

Includes one solid tray, one perforated tray, and two standard pasta dies.

Surface fan

Includes a surface fan.

Style Floor model
Duty Industrial grade
Production rate Up to 110 lb/hr; varies by pasta shape and recipe
Mixer configuration Double mixer
Front mixer flour capacity 22 lb
Front mixer batch production Up to 30 lb/batch (flour + liquid)
Top mixer flour capacity 18 lb
Top mixer batch production Up to 25 lb/batch (flour + liquid)
Cutting knife Automatic cutting knife for short pasta shapes
Control Touchscreen control
Water cooling Water cooling with digital temperature readout
Water connection Pre-plumbed water in and water out lines; 1/2 in BARB
Water line temperature 45-60 °F
Water supply 1 gallon/minute; 70 psi maximum
Construction Stainless steel
Auger Removable
Mixing arm Stainless steel
Surface fan Included
Casters 4
Electrical requirement 220 V / 60 Hz / 1 ph; 9 A
Plug NEMA L15-20P
Cord length 8 ft
Included trays 1 solid tray and 1 perforated tray
Included pasta dies 2 standard pasta dies
Product dimensions 26.5 in W x 45 in D x 63.5 in H
Product weight 535 lb
Shipping dimensions 27 in W x 45 in D x 64 in H
Weight 535 lb

Certifications & Compliance

Warranty & Protection

One-year warranty.

Documents

PDF Cutsheet PDF Download PDF Pasta shapes catalog PDF Download

Frequently Asked Questions

The AEX90M produces up to 110 lb/hr, with output varying by pasta shape and recipe.
The machine includes an automatic cutting knife for short pasta shapes, one solid tray, one perforated tray, and two standard pasta dies.
It requires 220 V / 60 Hz / 1-phase power at 9 amps and uses a NEMA L15-20P plug.
The machine is pre-plumbed for water in and water out lines. The cutsheet specifies a 1/2 in BARB connection, a 45-60 °F water line temperature, and a supply of 1 gallon per minute at 70 psi maximum.
The product measures 26.5 in wide by 45 in deep by 63.5 in high and has a catalog weight of 535 lb.
The supplied product evidence specifies a one-year warranty.
