Antunes

Antunes Vizion VZN-540H Horizontal Ultrafiltration Water Filtration System, 15 GPM, 0.015 Micron, No Carbon Cartridge

SKU: VZN-540H
$1,867.32
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Antunes Best Sellers Equipment New Arrivals Plumbing & Water Treatment Restaurant Equipment Water Filters

Antunes Vizion VZN-540H Horizontal Ultrafiltration Water Filtration System, 15 GPM, 0.015 Micron, No Carbon Cartridge

Stainless steel housing with self-cleaning filtration and global plug adapters.

A high-flow, self-cleaning horizontal ultrafiltration system delivers 15 GPM of 0.015-micron filtration with low maintenance.

  • Horizontal VZN system built without a carbon cartridge
  • 15 GPM service flow rate for high-demand beverage applications
  • 0.015-micron ultrafiltration helps remove sediment, cysts, and fine particles
  • Self-cleaning design and adjustable flush timer help reduce maintenance
  • Stainless steel housing built for commercial environments
  • 100-240V, 50/60 Hz, single-phase power with 10W draw and plug adapters for US, Europe, Australia, and UK
  • NSF certified at 13 GPM (49.2 LPM)
  • 3/4-inch plumbing connections with rinse port

Overall Dimensions:

50.0"W x 9.0"D x 17.0"H

Product Weight:

52.0 lb

Horizontal System Design

Horizontal VZN model without a carbon cartridge.

0.015-Micron Ultrafiltration

Fine filtration helps remove sediment, cysts, and particles as small as 0.015 microns.

Self-Cleaning Filtration

Self-cleaning ultrafilter helps reduce clogging and maintenance.

Stainless Steel Housing

Durable stainless steel ultrafilter housing for commercial use.

15 GPM Service Flow Rate

Supports up to 15 gallons per minute (57 LPM).

Universal Electrical Input

Runs on 100-240V, 50/60 Hz, single-phase power with a 10W draw and 0.08A current.

Global Plug Adapters Included

Includes plug adapters for the US, Europe, Australia, and UK.

Adjustable Flush Timer

Built-in adjustable flush timer supports setup and maintenance.

NSF-Certified Performance

Documented NSF certification at 13 GPM (49.2 LPM).

Plumbing Connections

Uses 3/4-inch inlet, outlet, and drain connections with a 3/4-inch GHT rinse port.

Type Ultrafiltration System
Style Horizontal
Material Stainless Steel
Micron Rating 0.015 Microns
Service Flow Rate 15 GPM (57 LPM)
Maximum Operating Temperature 104°F (40°C)
Maximum Operating Pressure 100 psig
Voltage 100-240 Volts
Hertz 50/60 Hz
Phase 1-Phase
Amps 0.08 Amps
Watts 10 Watts
Plug Type Cord with Plug Adapters
Water Inlet Size 3/4 Inch FNPT
Water Outlet Size 3/4 Inch FNPT
Drain Connection Size 3/4 Inch FNPT
Rinse Connection Size 3/4 Inch GHT
Shipping Width 50 Inches
Shipping Depth 9 Inches
Shipping Height 17 Inches
Shipping Weight 52 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

It is a horizontal ultrafiltration water filtration system without a carbon cartridge.
No. The VZN-540H is the horizontal system without a carbon cartridge.
It filters down to 0.015 microns and is rated for 15 GPM (57 LPM); the document lists NSF certification at 13 GPM (49.2 LPM).
It uses 100-240V, 50/60 Hz, single-phase power, draws 10W, and 0.08A, and includes cord plug adapters for US, Europe, Australia, and UK.
The unit uses 3/4-inch inlet, outlet, drain, and rinse connections.
The maximum operating temperature is 104°F (40°C).
