American Range  |  SKU: ARSHP-48-4

American Range ARSHP-48-4 Hot Plates

$2,379.13
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Warranty sheet
Related Searches
Commercial Hot Plates Commercial Ranges Hot Plates Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

American Range ARSHP-48-4 Gas Hot Plate – 48" Countertop, 4-Burner

128,000 BTU | Manual Controls | Built & Certified in the USA

Rugged, reliable and ready for the rush, the American Range ARSHP-48-4 packs four powerful 32,000 BTU open burners into a low-profile 48" countertop unit. Heavy-duty cast-iron grates and all-stainless exterior surfaces stand up to the harshest commercial environments, while individual manual valves give cooks precise, instant control at every station.

Why You’ll Love It
  • Four open burners, each delivering 32,000 BTU/hr (total 128,000 BTU).
  • 12" × 12" sectional cast-iron top grates lift off for quick cleaning and re-configuration.
  • Individual manual gas valves and standing pilots on every burner for immediate ignition.
  • Full-width removable stainless steel crumb tray keeps the workspace tidy.
  • Stainless steel front, sides, landing ledge and 4" backguard resist corrosion and splatter.
  • Low 12 9/16" profile with 4" adjustable stainless inset legs for perfect counter alignment.
  • 3/4" rear NPT gas connection – field convertible for Natural Gas or LP.
  • Certified cETLus & ETL-Sanitation for use in commercial kitchens nationwide.
  • Designed & built in the USA; protected by a 2-year limited parts & labor warranty.
Specifications
Model ARSHP-48-4
Configuration Countertop hot plate, open burners
Burners 4 × 32,000 BTU open burners
Total Input 128,000 BTU/hr
Grate Size 12" × 12" cast iron (removable)
Overall Width 48" (1219 mm)
Overall Depth 30" (762 mm)
Overall Height 12 9/16" (319 mm) with legs lowered
Gas Connection 3/4" NPT rear
Manifold Pressure Natural Gas 5.0" WC  |  LP 10.0" WC
Clearances – Combustible 12" sides | 4" rear | 0" bottom on non-combustible counter
Net / Ship Weight ≈ 140 lb (shipping weight may vary)
Certifications cETLus, ETL-Sanitation
Warranty 2-year limited parts & labor
Perfect For
  • Busy restaurant sauté or stock stations
  • Catering & banquet prep kitchens
  • Food trucks, ghost kitchens & pop-ups needing a portable high-BTU solution
  • Institutional foodservice – schools, hospitals, corporate dining
Optional Accessories (sold separately)
  • Stainless steel equipment stand
  • Casters for stand mobility
Installation note: This appliance must be installed, converted (if required) and serviced by a qualified gas technician. Provide adequate ventilation and follow all local codes and NFPA 96 guidelines. Specify gas type and altitude (over 2,000 ft) when ordering.

Need a different size or burner count? The American Range ARSHP series is also available in 12", 24", 36" and 60" widths with up to 10 burners.

Features & Specs

Manufacturer

American Range

Certifications

cETLus, ETL-Sanitation, Made in USA

Height

10.0in

Width

48.0in

Depth

18.0in

Shipping Weight

140.0lbs

Legs

without legs

Width (side - side)

48 - 59"

Burner Qty

4 burners

Top and Front Finish

stainless steel front & sides

Specifications

Hotplate, gas, 48" wide, countertop,(4) 32,000 BTU open burner with 12" x 12" sectional cast iron top grates, manual controls, pilot, removable crumb tray, stainless front & sides, 4" backguard, 4" adjustable legs cETLus, ETL-Sanitation, Made in USA
