American Range ARSHP-24-4 Hot Plates
Description
American Range ARSHP-24-4 Gas Hot Plate – 24" Countertop
Made in USA | 128,000 BTU | cETLus & ETL-SanitationPack powerhouse performance into a compact footprint. The American Range ARSHP-24-4 delivers four individually-controlled 32,000 BTU open burners under heavy-duty cast-iron grates, giving busy kitchens the searing heat and rugged reliability they demand—without sacrificing valuable line space.
Key features
- Four 32,000 BTU/hr two-piece, lift-off open burners (128,000 BTU total).
- Removable 12" × 12" sectional cast-iron grates support heavy stock pots and clean easily.
- Manual gas valves with standing pilots for instant, independent ignition on every burner.
- Full-width stainless steel crumb tray slides out from the front for fast cleanup.
- Durable stainless steel front, sides & 4" backguard resist corrosion and denting.
- 4" adjustable legs let you level the unit on any countertop.
- Die-cast red control knobs are easy to grip and built for daily abuse.
- Field-convertible for natural gas or LP (3/4" rear connection).
- cETLus & ETL-Sanitation listed for gas safety and NSF-equivalent sanitation.
- Designed, engineered & built in the USA.
Technical specifications
| Model | ARSHP-24-4 |
|---|---|
| Configuration | Countertop gas hot plate, 4 open burners |
| Overall width | 24" (610 mm) |
| Overall depth | 30" (762 mm) |
| Overall height | 12 9/16" (319 mm) + 4" adjustable legs |
| Burner output | 32,000 BTU/hr each | 128,000 BTU/hr total |
| Grate size | 12" × 12" sectional cast iron |
| Gas connection | 3/4" NPT (rear) |
| Gas type | Natural or LP (specify when ordering) |
| Controls | Manual valves, standing pilots |
| Crum tray | Full-width, removable stainless steel |
| Construction | Stainless steel front & sides; cast-iron burners & grates |
| Certifications | cETLus, ETL-Sanitation |
| Shipping weight | Approx. 145 lb (66 kg) |
| Warranty | 2-year limited parts & labor (see details below) |
Clearance & installation
- Use only on non-combustible countertops.
- Legs or casters are required—or provide a 2" (51 mm) overhang when curb-mounted.
- Maintain clearances of 12" (305 mm) at the sides and 4" (102 mm) at the rear when next to combustible surfaces.
- Requires adequate ventilation per NFPA 96.
Professional installation by a qualified technician is recommended. Specify gas type and altitude (>2,000 ft) when ordering.
Warranty
American Range backs the ARSHP-24-4 with a two-year limited parts & labor warranty (90 days on replacement parts, broiler burners, grates and radiants). Register your equipment within 90 days of shipment to qualify for extended coverage.
