American Range ARMG-48-24 Gas Griddles
Description
American Range ARMG-48-24 Manual Gas Griddle — 48" x 24"
Countertop • 120,000 BTU • 1" polished steel plate • Made in USAEngineered for high-volume kitchens, the American Range ARMG-48-24 pairs a massive 48" wide cooking zone with four powerful U-shaped burners for lightning-fast recovery and perfectly even heat. From breakfast rush to late-night service, this rugged stainless steel griddle keeps your line moving and your food sizzling.
Key Features
- 48" W x 24" D (1,152 sq in) cooking surface handles multiple menu items at once.
- Polished 1" (25 mm) thick steel plate for superior heat retention and easy cleaning.
- Four independent 30,000 BTU U-shaped burners (one every 12") deliver a total of 120,000 BTU/hr.
- Front-mounted manual gas valves give chefs instant temperature control.
- 3" welded splash guard and extra-wide 6¼" landing ledge keep work stations clean and safe.
- Full-width 3" stainless grease trough drains to a removable, easy-empty grease pan.
- All-stainless exterior (front, sides, landing ledge & splash) stands up to daily abuse.
- 4" adjustable stainless steel legs level the unit on any countertop.
- ¾" NPT rear gas connection — field convertible for Natural or LP gas (specify at checkout).
- ETL Sanitation & Gas certified; designed and built in California, USA.
At-a-Glance Specs
| Manufacturer | American Range |
|---|---|
| Model # | ARMG-48-24 |
| Gas Type | Natural or LP (field convertible) |
| Total Input | 120,000 BTU/hr (35.0 kW) |
| Burners | 4 U-shaped, 30,000 BTU each |
| Cooking Surface | 48" W x 24" D, 1" thick polished steel |
| Overall Dimensions | 48" W x 35" D x 17" H |
| Splash Guard | 3" rear & sides (welded) |
| Grease Management | 3" trough with removable pan |
| Legs | 4" adjustable stainless steel |
| Gas Connection | ¾" NPT (rear, right-hand) |
| Certifications | ETL Sanitation, ETL Gas (US & Canada) |
| Warranty | 2-year limited parts & labor |
| Origin | Made in USA |
Installation & Clearance Notes
- Suitable for non-combustible counters/floors — 4" legs supplied (or 2" curb base required).
- Clearances to combustible construction: 12" each side, 4" rear; zero clearance to non-combustible walls.
- Install under an exhaust hood that complies with NFPA-96 or local code requirements.
Specify gas type and site altitude when ordering. Approximate shipping weight: 490 lb (includes packaging).
