American Range ARGF-8 Gas Ranges
Description
48" Green Flame Gas Range – 8 Burners & Dual 20" Space-Saver Ovens
Model ARGF-8 | 254,000 BTU | Natural or LP | Made in USABuilt for high-volume kitchens that refuse to compromise on efficiency, the American Range Green Flame ARGF-8 delivers blistering power, precise electronic ignition and the rugged stainless-steel construction you trust. Eight 25,000 BTU open burners sit above two independent 20" Space Saver ovens, giving chefs the flexibility to sauté, sear, bake and roast simultaneously—all in a single, 48-inch footprint.
Why You’ll Love It
- Eight 25,000 BTU open burners with pilot-less electronic ignition—no standing pilots to waste energy.
- 12" × 12" heavy-duty cast-iron top grates keep cookware stable and hold heat between cycles.
- Two 27,000 BTU Space Saver ovens (20" W) with 250-500 °F thermostat, porcelain interiors and spring-assisted doors.
- Stainless-steel front, sides, backguard and 6" deep front landing ledge for easy cleaning and long service life.
- Choice of 6" stub back, 20" riser or high shelf/riser—select the configuration that matches your ventilation system.
- Adjustable 6" chrome-plated legs; field-installable swivel casters available.
- 100 % gas shut-off safety system and rear gas connection with 3/4" NPT regulator supplied.
- Powered ignition requires only a standard 115 V, 1-ph, 3-prong outlet.
Space Saver Oven Performance
- Interior: 20" W × 26-1/2" D × 13-1/2" H, fits standard sheet pans front-to-back.
- Two chrome-plated racks per oven on four position guides (add-on racks optional).
- Porcelain-enameled liner wipes clean quickly and resists corrosion.
- Counter-weighted door stays open at any angle—no slamming.
Technical Specs
| Overall Width | 48" (1219 mm) |
|---|---|
| Depth (front–back) | 32-1/2" (826 mm) |
| Height w/ 6" Stub Back | 56" (1422 mm) to top of stub |
| Total BTU Input | 254,000 BTU/hr (74.0 kW) |
| Open Burners | 8 × 25,000 BTU (cast iron grates, electronic ignition) |
| Ovens | 2 × 27,000 BTU Space Saver ovens |
| Gas Connection | 3/4" NPT (rear) |
| Manifold Pressure | Nat 5.0" W.C. | LP 10.0" W.C. |
| Electrical | 115 V, 1-ph, 0.5 A (ignition & controls) |
| Certifications | cETLus, ETL-Sanitation |
| Origin | Designed & built in the USA |
| Warranty | 2-year parts & labor limited warranty |
Factory Options (sold separately)
- Swivel caster kit (set of four, front brakes)
- High riser with heavy-duty shelf
- Extra oven racks
- Storage cabinet base (replaces ovens)
American Range reserves the right to improve products; specifications are subject to change without notice. Full warranty terms available at americanrange.com.
