American Range | SKU:
ARGF-4-SB
American Range ARGF-4-SB Gas Ranges
$6,329.38
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
American Range ARGF-4-SB Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
American Range ARGF-4-SB Gas Ranges
$6,329.38
Unit price
/
Unavailable
Description
American Range 24" Green Flame Gas Range – 4-Burner with 20" Storage Base
Model ARGF-4-SB | Built & Engineered in the USAPower, efficiency and a compact footprint come together in the Green Flame 24" range. Four 25,000 BTU open burners ignite electronically—no standing pilots—while a 20" space-saver storage cabinet keeps essentials right where you need them.
Key Benefits
- Four high-output 25,000 BTU burners (100,000 BTU total) for lightning-fast heat response.
- Pilot-free electronic ignition slashes energy costs and lowers kitchen heat.
- Heavy-duty 12" × 12" cast-iron grates lift off individually for sink-side cleaning.
- Full-width removable drip pan simplifies nightly clean-up.
- 20" storage base maximizes vertical space—ideal for pans, lids and utensils.
- 6" deep front landing ledge adds extra prep & plating real estate.
- All-stainless front, sides and backsplash for unmatched durability and easy wipe-down.
- 6" chrome-plated adjustable legs level the unit on uneven floors.
- Free backguard choice: 6" stub, 20" riser or high riser with shelf.
- cETLus & ETL-Sanitation listed for commercial kitchens across North America.
- Protected by a 2-year limited parts & labor warranty.
Technical Specifications
| Width | 24" / 610 mm |
|---|---|
| Depth | 32 1/2" / 826 mm (to landing ledge) |
| Cooktop Height | 36" / 914 mm (legs at lowest setting) |
| Overall Height | 56" / 1,422 mm (with 20" riser) |
| Open Burners | 4 × 25,000 BTU (Natural or LP) |
| Total Output | 100,000 BTU/hr | 29.0 kW |
| Base Configuration | 20" space-saver storage cabinet (no oven) |
| Gas Connection | 3/4" NPT rear; 5.0" W.C. Nat / 10.0" W.C. LP |
| Electrical | 115 V, 1 ph, 15 A (factory-installed 3-prong cord) |
| Certifications | cETLus, ETL-Sanitation |
| Shipping Weight | Approx. 245 lb / 111 kg |
Perfect For
- Space-conscious restaurant cooklines
- Food trucks & ghost kitchens demanding maximum BTU per inch
- Cafés, diners and concessions upgrading from countertop units
Gas Type Required: Specify Natural or LP gas when ordering. For installations above 2,000 ft
(610 m) elevation, consult local codes for de-rating requirements.
Questions about configuration, accessories or lead times? Our equipment specialists are ready to help.
Features & Specs
Features & Specs
Manufacturer
American Range
Certifications
cETLus, ETL-Sanitation, Made in USA
Height
36.0in
Width
24.0in
Depth
32.5in
Shipping Weight
355.0lbs
Top
(4) open burners
Vent
backriser with hi-shelf
Base
(1) space saver oven
Exterior Finish
stainless steel front & sides
Specifications
Green Flame Range, gas, 24", (4) 22,000 BTU open burners, (1) 20" space saver storage base, pilotless burner ignition systems, stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 29.0kW, 100,000 BTU, cETLus, ETL-Sanitation, Made in USA
