American Range ARGF-24G-2B Gas Ranges
American Range ARGF-24G-2B Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
American Range ARGF-24G-2B Gas Ranges
Description
American Range Green Flame™ 36″ Gas Range – 24″ Griddle, 2 Open Burners & Standard Oven
Model: ARGF-24G-2B | Made in the USABuilt for high-volume kitchens that refuse to compromise on efficiency, the Green Flame™ series uses pilot-less electronic ignition to slash energy waste while delivering legendary American Range durability. This 36″ combo range pairs a restaurant-sized 24″ griddle with two 25,000 BTU open burners and a full-width standard oven—giving chefs the versatility to sear, sauté, scramble, bake and roast from one compact footprint.
Key Features
- 36″ (914 mm) cabinet-width—specify Natural Gas or LP
- 24″ (610 mm) manual griddle, 1″ thick polished steel plate for superior heat retention
- (2) 25,000 BTU lift-off open burners with heavy-duty 12″ × 12″ cast-iron grates
- Pilot-less electronic ignition on every burner—no standing pilots
- 26-1/2″ wide standard oven, 35,000 BTU, 250 °F – 500 °F (121 °C–260 °C) range
- Porcelain-enamel oven interior, spring-assisted counterweighted door & cool-touch handle
- Total input: 135,000 BTU/hr (≈ 40 kW)
- Stainless-steel front, sides, landing ledge & 6″ deep front rail
- Choice of backsplash: 20″ high shelf & riser, 20″ riser only, or 6″ stub back
- 6″ chrome-plated adjustable legs (optional locking casters available)
- cETLus & ETL-Sanitation listed
Performance Highlights
- One 20,000 BTU burner every 12″ beneath the griddle guarantees fast recovery & even temps.
- Removable full-width drip pan and split crumb trays simplify end-of-shift clean-up.
- 100 % gas-shut-off safety valve provides peace of mind for operators.
- Lift-off open-burner heads and cast-iron grates withstand years of heavy use.
Specifications
| Overall width | 36″ (914 mm) |
|---|---|
| Depth (incl. landing ledge) | 32-1/2″ (826 mm) |
| Height to cooktop | 36″ (914 mm) |
| Griddle surface | 24″ W × 24″ D × 1″ thick (610 × 610 × 25 mm) |
| Open-burner rating | (2) × 25,000 BTU/hr |
| Griddle burners | (2) × 20,000 BTU/hr |
| Oven burner | 35,000 BTU/hr |
| Total input | 135,000 BTU/hr (40 kW) |
| Oven cavity (W × D × H) | 26-1/2″ × 22-1/2″ × 13-1/2″ (673 × 572 × 343 mm) |
| Electrical | 115 V, 1-ph, 60 Hz, 15 A, 3-prong cord (ignition only) |
| Gas connection | 3/4″ NPT rear manifold – 5.0″ W.C. NG / 10.0″ W.C. LP |
| Shipping weight | ≈ 450 lb (204 kg) |
What’s Included
- (2) chrome-plated oven racks with 4-position guides
- Full-width removable drip pan & split crumb trays
- 6″ chrome-plated adjustable legs
- Factory pressure regulator & 6-ft power cord
- Stainless-steel backsplash option of your choice (select when ordering)
Warranty
Protected by American Range’s 2-year limited parts & labor warranty (90-day coverage on replacement parts, broiler burners, grates & radiants). Full details available in the warranty document.
