American Range ARGF-12G-2B-SB Gas Ranges
American Range ARGF-12G-2B-SB Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
American Range ARGF-12G-2B-SB Gas Ranges
Description
24" Green Flame Range with 12" Manual Griddle, 2 Open Burners & 20" Storage Base
American Range • Model ARGF-12G-2B-SBPurpose-built for compact cook lines, the Green Flame 24" range delivers the versatility of a heavy-duty griddle and high-output open burners, all above a convenient space-saver storage cabinet. With stainless steel construction throughout and pilotless electronic ignition, this U.S.-made workhorse is ideal for short-order restaurants, cafés, food trucks and satellite kitchens that demand reliability in a small footprint.
Highlights at a Glance
- 12" (305 mm) left-side steel griddle, 1" thick plate for superior heat retention
- (2) 25,000 BTU open burners with heavy-duty cast-iron top grates
- Pilotless electronic ignition on burners & griddle – no standing pilots, lower energy use
- 20" space-saver storage cabinet base with door (no oven to heat up or clean)
- Manual control valves for both burners and griddle (thermostatic upgrade available)
- Stainless steel front, sides & back for easy wipe-down durability
- 6" deep front landing ledge keeps plating & pans within reach
- Choice of backguard at no extra charge: 6" stub back, 20" riser, or high riser with shelf
- Adjustable 6" chrome-plated legs; optional casters for roll-away mobility
- cETLus & ETL-Sanitation listed • Made in the USA
Technical Specifications
| Overall width | 24" / 610 mm |
|---|---|
| Overall depth | 34" / 864 mm |
| Cooking surface height | 36" / 914 mm (with 6" legs) |
| Height with 20" riser | 56" / 1422 mm |
| Total input | 70,000 BTU hr (21.0 kW) |
| Open burners | 2 × 25,000 BTU; removable drip pan under each grate |
| Griddle burner | 1 × 20,000 BTU; 12" × 27" cook zone |
| Gas connection | 3/4" NPT rear; Natural 5.0" W.C. or Propane 10.0" W.C. |
| Electrical | 115 V, 1 ph, 15 A, 3-prong cord (ignition & controls) |
| Shipping weight | Approx. 260 lb / 118 kg |
| Warranty | 2-year parts & labor (90-day on replacement parts) |
Installation Notes
- Intended for non-combustible floors; legs or casters are required
- When placed next to combustibles, maintain 12" side and 4" rear clearances
- An adequate ventilation system complying with NFPA 96 is required
- Specify gas type (Natural or LP) and altitude when ordering
Register your equipment within 90 days of shipment to activate the extended warranty. Full terms available at americanrange.com/terms-of-sale.
