American Range AR-6B-36RG Gas Ranges
Description
American Range AR-6B-36RG 72" Gas Restaurant Range
6 Open Burners • 36" Raised Griddle/Broiler • 2 Standard OvensBring menu-spanning versatility to the cookline with this 72-inch powerhouse from American Range. The AR-6B-36RG combines high-output open burners, a raised griddle/broiler and twin ovens—delivering a staggering 322,000 BTU of made-in-the-USA performance in one durable, stainless-steel platform.
- Six 32,000 BTU open burners with no-clog, lift-off heads & 12" × 12" cast-iron grates
- 36" raised griddle/broiler on right side – 3/4" thick polished steel plate, 3" grease trough & one 20,000 BTU burner every 12"
- Two 26-1/2" standard ovens, each with a 35,000 BTU steel burner, 250-500 °F thermostat & two chrome racks
- Stainless steel front, sides, backsplash & 6" deep landing ledge built for heavy-duty use
- Choice of 20" high riser with storage shelf or 6" stub back included at no charge
- 6" adjustable chrome-plated legs (locking casters optional)
- Full-width removable drip pan under burners for quick clean-up
- Individual manual gas valves & standing pilots on every burner for instant ignition
- cETLus & ETL Sanitation listed for commercial kitchens
- Proudly designed & built in the USA and backed by a 2-year parts & labor warranty
Performance at a Glance
| Model | AR-6B-36RG |
|---|---|
| Gas Type | Natural or Propane (specify when ordering) |
| Total Input | 322,000 BTU/hr (95.0 kW) |
| Open Burners | 6 × 32,000 BTU lift-off |
| Raised Griddle/Broiler | 36" W × 24" D, 3/4" plate, 3 × 20,000 BTU |
| Standard Ovens | 2 × 35,000 BTU Interior: 26-1/2" W × 22-1/2" D × 13-1/2" H (2) chrome racks each |
| Thermostat Range | 250 °F – 500 °F (121 °C – 260 °C) |
| Dimensions (W × D × H) | 72" × 32-1/2" × 36" cooking height 56" overall height with 20" riser |
| Gas Connection | 3/4" NPT; 5.0" W.C. Natural, 10.0" W.C. Propane |
| Shipping Weight | Approx. 855 lb (388 kg) |
What’s in the Box
- (2) Chrome racks per oven
- Removable grease drawer & drip pan
- 20" high backguard with shelf or 6" stub back
- Installation & operation manual plus warranty registration
Specifications are subject to change without notice as American Range continually improves its products.
