American Range  |  SKU: AR-3RB-SB

American Range AR-3RB-SB Gas Ranges

$7,361.55
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Cutsheet Cutsheet Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

American Range AR-3RB-SB 36" Gas Radiant Broiler Range with Storage Base

90,000 BTU • Manual Controls • Made in USA

Turn up the heat and clear the clutter with American Range’s 36-inch AR-3RB-SB. This heavy-duty restaurant range pairs a high-performance radiant charbroiler top with a roomy under-cabinet storage base—perfect for kitchens that crave grilling power without losing valuable floor space.

Key Features
  • True 36" broiler deck driven by six 15,000 BTU steel burners (90,000 BTU total).
  • Cast-iron radiants and reversible, extra-thick cast-iron grates deliver even heat and bold sear marks.
  • One manual gas valve & pilot per burner—create up to six independent heat zones.
  • Full-width removable drip pan for fast, tool-free cleanup.
  • 26 ½" stainless storage base holds hotel pans, sheet trays, or dry goods right under the grill.
  • All-stainless front, sides, 6" stub back and a 6" deep landing ledge stand up to daily abuse.
  • 6" chrome-plated adjustable legs provide a 38" cooking height; optional casters available.
  • Field-convertible for Natural or LP gas • 3/4" rear NPT connection with regulator.
  • cETLus & ETL-Sanitation listed for gas safety and food-service hygiene.
  • Backed by a two-year limited parts & labor warranty; designed & built in the USA.
Technical Specifications
Model AR-3RB-SB
Equipment type Radiant broiler range w/ storage base
Overall width 36" / 914 mm
Depth (incl. stub back) 32 ½" / 825 mm
Cooking height 38" / 965 mm
Burners 6 × 15,000 BTU steel tube
Total input 90,000 BTU/hr (27 kW)
Manifold pressure Natural 5.0" W.C. • LP 10.0" W.C.
Gas connection 3/4" NPT (rear, regulator included)
Clearances to combustibles 12" sides • 4" rear (0" to non-combustibles)
Certifications cETLus, ETL-Sanitation
Warranty 2-year parts & labor (broiler burners, grates & radiants 90 days)
Installation tip: Minimum 400 CFM per linear foot of hood is recommended for charbroiler equipment. Verify local code requirements before ordering.

Looking for the same power with a built-in oven? See model AR-3RB.

Features & Specs

Manufacturer

American Range

Height

56.0in

Width

36.0in

Depth

32.25in

Shipping Weight

570.0lbs

Exterior Finish

stainless steel front & sides

Base

(1) cabinet

Vent

stub back

Top

(1) charbroiler

Specifications

Restaurant Range, gas, 36", charbroiler, cast iron radiants, reversible top grates, manual controls, (1) 26 1/2" storage space, stainless steel front, sides & 6" stub back, 6" chrome plated legs, 27.0kW, 90,000 BTU, cETLus, ETL-Sanitation, Made in USA
