American Range 24" Gas Radiant Charbroiler Range w/ Storage Base – 60,000 BTU
Model AR-2RB-SB | cETLus & ETL-Sanitation Listed | Made in USABring true charbroiler performance to tight cooking lines. The AR-2RB-SB packs 60,000 BTU of flame-kissed power into a space-saving 24 inch footprint and swaps the oven for a 20 inch storage cabinet—perfect for holding sheet pans, utensils, or dry goods.
Key Features
- 4 heavy-duty 15,000 BTU steel burners (one every 6") for even, controllable heat.
- Cast-iron radiants and fully reversible 6" grates deliver classic char-marks and superior heat retention.
- Manual control valve and stainless-steel standing pilot on each burner for simple, reliable operation.
- Full-width removable drip pan speeds end-of-shift clean-up.
- Durable stainless-steel front, sides and 6" stub back stand up to daily commercial abuse.
- 20" storage base maximizes vertical space—no oven to heat, no racks to lose.
- 6" chrome-plated adjustable legs for a level, code-compliant installation (optional swivel casters available).
- Two-year limited parts & labor warranty backed by American Range’s nationwide service network.
At-a-Glance Specs
| Cooking surface width | 24" / 610 mm |
|---|---|
| Overall depth | 32 1/2" / 826 mm |
| Cooking height | 38" / 965 mm |
| Burners | 4 × 15,000 BTU steel tube |
| Total output | 60,000 BTU/hr (18.0 kW) |
| Grates | Reversible cast-iron, 6" sections |
| Radiants | Heavy-duty cast iron |
| Controls | 4 manual gas valves, standing pilots |
| Base type | 20" storage cabinet (no oven) |
| Gas inlet | 3/4" NPT, rear |
| Manifold pressure | 5" W.C. Natural | 10" W.C. LP |
| Shipping weight | ≈ 400 lb / 181 kg (crated) |
| Certifications | cETLus, ETL-Sanitation |
| Country of origin | Designed & built in the USA |
Broiler burners, radiants and grates carry a 90-day warranty; all other components are covered for 24 months (parts & labor).
Included & Optional Items
- Included: 6" chrome-plated adjustable legs, factory-installed pressure regulator.
- Optional: Swivel casters with front brakes, natural ↔ LP conversion kit.
Gas notice: Specify gas type and altitude (if > 2,000 ft) when ordering. Install under an approved commercial ventilation system on a non-combustible floor.
$6,670.03
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
American Range AR-2RB-SB 24" gas charbroiler: commercial-grade stainless steel, cast iron radiants, reversible grates, 60,000 BTU, ETL-Sanitation.
Manufacturer
American Range
Height
44.0in
Width
24.0in
Depth
32.25in
Shipping Weight
400.0lbs
Base
(1) cabinet
Exterior Finish
stainless steel front & sides
Specifications
Restaurant Range, gas, 24", charbroiler, cast iron radiants, reversible top grates, manual controls, (1) 20" storage space, stainless steel front, sides & 6" stub back, 6" chrome plated legs, 18.0kW, 60,000 BTU, cETLus, ETL-Sanitation, Made in USA
