American Range AR-24G-8B-DSB Gas Ranges
Description
American Range 72" Gas Restaurant Range – 24" Griddle & 8 Open Burners
Model AR-24G-8B-DSB | Made in USABring powerhouse versatility to your cookline with this 72" American Range gas restaurant range. A heavy-duty 24" griddle teams up with eight high-performance open burners, while twin 26-1/2" storage bases keep sheet pans and smallwares within arm’s reach—all in a rugged, stainless-steel package built and certified for the demands of commercial kitchens.
Key Features
- 24" manual-control griddle on the left, crafted from a 1" thick polished steel plate for fast recovery and even heat.
- Eight lift-off open burners rated at 32,000 BTU/hr each; 12" × 12" cast-iron top grates remove for quick cleaning.
- Two 26-1/2" insulated storage bases (no ovens) provide convenient under-counter equipment or sheet-pan storage.
- Stainless steel front, sides, and 6" deep front landing ledge stand up to daily abuse and simplify wipe-downs.
- Choice of flue system included: 6" stub back, 20" riser, or high shelf & riser—specify at time of order.
- 6" chrome-plated adjustable legs level the unit on any surface and set a comfortable 36" cooking height.
- Rear ¾" NPT gas connection comes with factory pressure regulator for easy hook-up.
- cETLus & ETL-Sanitation listed; NSF-compliant construction for food-service safety.
- Backed by a 2-year parts & labor warranty and supported coast-to-coast.
Performance Specs
| Overall width | 72" (1829 mm) |
|---|---|
| Overall depth | 32-1/2" (825 mm) |
| Cooking height | 36" (914 mm) |
| Griddle size | 24" W × 24" D × 1" thick (610 × 610 × 25 mm) |
| Griddle burners | 2 × 20,000 BTU/hr (11.7 kW) |
| Open burners | 8 × 32,000 BTU/hr (75 kW) |
| Total input | 296,000 BTU/hr (87.0 kW) |
| Gas type | Natural or LP (specify when ordering) |
| Manifold pressure | NG 5.0" W.C. / LP 10.0" W.C. |
| Gas inlet size | ¾" NPT (19 mm) |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 2-year parts & labor; 90-day replacement parts |
| Manufactured | North Las Vegas, NV & Pacoima, CA, USA |
Perfect For
- High-volume restaurants & diners
- Hotel, resort & casino kitchens
- Catering commissaries and ghost kitchens
- University & corporate food-service operations
Need swivel casters, thermostatic griddle control, or other custom options? Let us know—American Range builds to order so your range fits your workflow perfectly.
