American Range AR-12G-4B-SB Gas Ranges
Description
American Range 36" Restaurant Range – 4 Burners • 12" Griddle • Storage Base
Model reference: AR-12G-4B-SB | cETLus & ETL-Sanitation ListedBuilt, engineered, and certified in the USA, this 36" American Range gas restaurant range pairs the blistering heat of four 32,000 BTU open burners with the versatility of a 12" manual-control griddle. A full-width 26 ½" storage base keeps sheet pans and smallwares close at hand, while the all-stainless body, removable drip pans, and 1" thick griddle plate make daily clean-up fast and painless.
Key Features
- 4 x 32,000 BTU lift-off open burners (128,000 BTU total) with 12" × 12" cast-iron grates
- Left-side 12" griddle, 1" thick steel plate, 20,000 BTU burner & 3" grease trough
- 26 ½" wide storage cabinet base replaces the traditional oven – perfect for pans, lids & cleaning tools
- Stainless steel front, sides, landing ledge, & backsplash for maximum kitchen durability
- Choice of backsplash: 6" stainless stub back, 20" riser, or high riser with shelf (select at no extra charge)
- 6" chrome-plated adjustable legs simplify leveling on uneven floors
- Removable, full-width drip pan under the rangetop speeds nightly maintenance
- Field convertible for Natural or LP gas (specify at time of order)
- Two-year limited parts & labor warranty backed by American Range’s nationwide service network
Performance Specifications
| Total input (Natural Gas) | ≈148,000 BTU/hr (43.4 kW)* |
|---|---|
| Open burners | 4 × 32,000 BTU/hr, lift-off heads, individual manual valves |
| Griddle burner | 20,000 BTU/hr, manual valve, 1" plate |
| Cooking surface | 36" W × 32 ½" D | 36" working height |
| Storage base interior | 26 ½" W × 22 ½" D × 24" H (approx.) |
| Gas connection | ¾" NPT rear manifold; 5.0" W.C. NG | 10.0" W.C. LP |
| Overall dimensions | 36" W × 32 ½" D × 56" H (with 20" riser) |
| Shipping weight | ≈355 lb (161 kg) |
*Total BTU rating shown for model with storage base. Ratings may vary slightly by gas type and altitude.
Built for Busy Kitchens
- Heavy-duty welded frame stands up to constant repositioning and high-volume abuse
- Stay-cool die-cast burner knobs allow precise flame control even during peak rushes
- Bright, recessed front panel indicators minimize snag points when maneuvering stockpots
- Grease drawer and drip pans slide completely out for sink-side scrubbing
Compliance & Warranty
- Certified to cETLus & ETL-Sanitation standards for gas equipment
- Designed & manufactured in North Las Vegas, NV, USA
- 2-year parts & labor warranty (90-day on replacement parts) – see full limited warranty
