American Range AMSQ-36 Wood/Charcoal Grills
Description
American Range AMSQ-36 Wood-Fired Floor Broiler
36″ wide • 1 gas log-lighter burner • 30,000 BTU (9 kW)Give steaks, seafood and poultry an authentic wood-smoked flavor—without slowing service. The AMSQ-36 combines a heavy-duty stainless body with an integrated gas log lighter, so you can fire up mesquite, oak or lump charcoal at the touch of a knob.
Key benefits
- Built-in gas log-lighter burner with adjustable valve & standing pilot—no messy lighter fluid or electric starters required.
- Large stainless steel loading door and chute for fast, safe wood or charcoal replenishment during service.
- Open bottom grate design promotes continuous updraft for hotter, cleaner combustion and lower fuel costs.
- Fire box lined with refractory bricks to protect the cabinet from burn-out and extend service life.
- Heavy-duty round-rod cast-iron top grates leave bold, appetizing grill marks.
- Full stainless steel exterior stands up to daily commercial abuse and wipes down quickly.
- ETL Listed for safety, sanitation and U.S./Canada compliance.
At-a-glance specs
| Model | AMSQ-36 |
|---|---|
| Cooking width | 36 in (914 mm) |
| Depth × Height | 27 in × 18 in (689 mm × 457 mm) |
| Fuel | Wood or charcoal (gas only powers the log lighter) |
| Gas connection | 3⁄4″ NPT; 5.0″ W.C. NG or 10.0″ W.C. LP |
| Burners / BTU | 1 log-lighter burner | 30,000 BTU /hr (9 kW) |
| Shipping weight | 345 lb (157 kg) |
| Clearances* | 0″ non-combustible; 12″ sides & 4″ rear combustible |
*For use on non-combustible floors. Legs or stand—or a 2″ curb overhang—are required.
Installation & options
- Ships ready for natural or LP gas (specify when ordering).
- Requires field-supplied stand, equipment base or 4″ counter legs.
- Optional stainless open stand, 4″ adjustable legs, casters, quick-disconnect gas hose.
Warranty
One-year limited parts & labor on the broiler; 90-day coverage on burners, grates and radiants.
