American Panel Corporation

HURRiCHiLL Roll-In Self-Contained Blast Chiller/Shock Freezer, 200 lb. Capacity

SKU: AP20BCF200-3-RHH
$87,961.20
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?

HURRiCHiLL Roll-In Self-Contained Blast Chiller/Shock Freezer, 200 lb. Capacity

208V, 3-Phase, Stainless Steel, One Mobile Rack

Fast, self-contained roll-in chilling and freezing with touchscreen control and stainless steel durability.

  • Roll-in, self-contained blast chiller/shock freezer designed for one mobile rack.
  • Blast chills up to 200 lb. from 160°F to 38°F in 90 minutes and shock freezes up to 120 lb. from 160°F to 0°F in 240 minutes.
  • 7" glove-safe capacitive touchscreen with Quick Start and preset chill, freeze, thaw, and service functions.
  • Polished 304 stainless steel cabinet with 2" CFC-free polyurethane insulation and high-velocity indirect airflow.
  • Includes one heated core probe; optional USB, Wi-Fi, sanitation, and thaw accessories are available.
  • Requires 208V/60/3 power and a 30-amp circuit.

Overall Dimensions:

47.5"W x 42.0"D x 93.62"H

Product Weight:

1220.0 lb

Roll-In Self-Contained Design

Accepts one mobile rack and includes an integral 2" ramp for easier loading and unloading.

Blast Chill and Shock Freeze Performance

Rapidly cools food from 160°F to 38°F in 90 minutes or to 0°F in 240 minutes, depending on the cycle selected.

7-Inch Touchscreen Controller

Glove-safe capacitive touchscreen provides quick access to Soft Chill, Hard Chill, Shock Freeze, Quick Start, Food Thaw, Sterilize, Coil Defrost, Reports, Probe, and Settings functions.

304 Stainless Steel Cabinet

Constructed of polished type 304 stainless steel inside and out with 2" CFC-free, high-density polyurethane insulation.

Even Air Distribution

High-velocity indirect airflow is designed to cool all levels at identical rates for more consistent results.

Self-Contained Refrigeration System

Built-in refrigeration system includes multiple evaporator circuits, wash-down fans, a swing-out vent panel, and an integrated condensate drain.

HACCP Data Support

Controller supports HACCP logging with optional USB thumb drive export or Wi-Fi connectivity for monitoring and notifications.

Included Food Probe

One heated core temperature probe is included; additional probes are available as an option.

Type Blast Chiller/Shock Freezer
Style Roll-In
Installation Type Floor Model
Refrigeration Type Self-Contained
Controls Touchscreen
Capacity 200 lb.
Pan Capacity (20) 12" x 20" x 2.5" Pans or (10) 18" x 26" Pans
Material Stainless Steel
Interior Finish 304 Stainless Steel
Voltage 208 Volts
Amps 19.5 Amps
Hertz 60 Hz
Phase 3-Phase
Breaker Size 30 Amps
Drain Connection Required
Drain Connection Size 1 Inch FPT
Shipping Width 48 Inches
Shipping Depth 42 Inches
Shipping Height 94 Inches
Shipping Weight 1220 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

3-year parts and labor; compressor covered for an additional 2 years parts only.

Frequently Asked Questions

It accepts one mobile rack with maximum dimensions of 26"W x 32"D x 73.5"H.
The unit is rated for 200 lb. from 160°F to 38°F in 90 minutes and 120 lb. from 160°F to 0°F in 240 minutes.
It requires 208V, 60 Hz, 3-phase power and is field wired to a 30-amp circuit.
It includes a 7" glove-safe capacitive touchscreen with Quick Start and preset cycles such as Soft Chill, Hard Chill, and Shock Freeze.
Yes. One core temperature probe is provided with the unit.
The standard warranty is 3 years parts and labor. The compressor is covered for an additional 2 years parts only, and the warranty excludes food probes.
