American Panel Corporation

HURRiCHiLL Roll-In Remote Blast Chiller / Shock Freezer, 200 lb Chill / 120 lb Freeze, Right-Hand Hinged

SKU: AP20BCF200-2-RHH
$73,682.40
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

American Panel Corporation Best Sellers Blast Chillers Blast Chillers & Freezers Commercial Refrigeration Commercial Refrigerators New Arrivals Restaurant Equipment Walk-In Coolers & Freezers

HURRiCHiLL Roll-In Remote Blast Chiller / Shock Freezer, 200 lb Chill / 120 lb Freeze, Right-Hand Hinged

Accepts 1 mobile rack; stainless steel interior and exterior; 208V, 1-phase, field wired.

This roll-in blast chiller/shock freezer helps high-volume kitchens rapidly chill or freeze large batches with remote refrigeration flexibility and solid-state electronic control.

  • Roll-in design accepts one mobile rack for efficient loading and unloading.
  • Chills up to 200 lb from 160°F to 38°F in 90 minutes.
  • Freezes up to 120 lb from 160°F to 0°F in 240 minutes.
  • Remote refrigeration layout supports flexible installation planning.
  • Solid-state electronic control panel includes a VFD display, alarms, and a heated food probe.
  • Stainless steel interior and exterior are built for durability and easy cleaning.
  • Right-hand hinged door and field-wired 208V single-phase power configuration.

Overall Dimensions:

47.63"W x 42.0"D x 86.63"H

Product Weight:

1020.0 lb

Roll-In Rack Capacity

Designed to accept one mobile rack for roll-in loading; rack is not included.

Rapid Chill And Freeze Performance

Supports 200 lb of food chilling from 160°F to 38°F in 90 minutes and 120 lb of food freezing from 160°F to 0°F in 240 minutes.

Remote Refrigeration

Cabinet is built for remote refrigeration, allowing the refrigeration system to be located separately from the unit.

Solid-State Electronic Controls

Includes a solid-state electronic control panel with VFD display and alarms for monitoring operation.

Heated Food Probe

Supplied with one heated food probe to help monitor product temperature during cycles.

Stainless Steel Construction

Stainless steel interior and exterior provide durability and easier cleanup in demanding kitchen environments.

Right-Hand Hinged Door

This model is configured with a right-hand hinged door.

Electrical Requirements

Requires 208V, 60 Hz, single-phase power, draws 8.0 amps, and must be field wired on a 15 amp circuit.

Type Blast Chiller / Shock Freezer
Style Roll-In
Installation Type Floor Model
Refrigeration Type Remote
Capacity 200 Pounds Chill / 120 Pounds Freeze
Pan Capacity (20) 12" x 20" x 2.5" Pans or (10) 18" x 26" Pans
Controls Solid-State Electronic
Temperature Range 160°F to 38°F Chill / 160°F to 0°F Freeze
Material Stainless Steel
Interior Finish Stainless Steel
Voltage 208 Volts
Amps 8.0 Amps
Hertz 60 Hz
Phase 1-Phase
Breaker Size 15 Amps
Plug Type Field Wired
Shipping Width 48 Inches
Shipping Depth 42 Inches
Shipping Height 87 Inches
Shipping Weight 1020 Pounds
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

3-year parts and labor warranty

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Installation & operators manual PDF Download

Frequently Asked Questions

No. This model is remote refrigeration and requires a separate refrigeration system.
It accepts one mobile rack, not included, that holds (20) 12" x 20" x 2.5" pans or (10) 18" x 26" pans.
It chills 200 lb from 160°F to 38°F in 90 minutes and freezes 120 lb from 160°F to 0°F in 240 minutes.
The unit requires 208V, 60 Hz, single-phase power, draws 8.0 amps, is field wired, and needs a 15 amp circuit.
Yes. One heated food probe is included.
This model is right-hand hinged.
