Alto-Shaam  |  Vector Series  |  SKU: VMC-F3G

Alto-Shaam VMC-F3G Vector Series Combi Ovens

$28,971.20
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Terms & conditions Spec sheet - french canadian Terms & conditions Spec sheet - spanish Spec sheet - ul Universal stand guide Cheflinc connectivity requirements Installation program Warranty sheet Warranty sheet
Related Searches
Alto-Shaam Bar Trays Combi Ovens Combi Ovens Ovens Smallwares Trays & Accessories

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Alto-Shaam Vector® F3G Gas Multi-Cook Oven

3 independent chambers. 1 game-changing footprint.

Replace multiple pieces of equipment—and the labor that goes with them—with the power, speed and precision of Structured Air Technology®. The Vector F3G delivers unmatched throughput and menu flexibility, letting you simultaneously cook three different items at three different temperatures with zero flavor transfer.

Key benefits

  • Three ovens in one – independent temperature, fan speed & cook time for every chamber.
  • High-volume capacity – holds 3 full-size sheet pans or 6 half-size sheet pans.
  • Exclusive Structured Air Technology® – focused vertical airflow for faster, more even cooking without pan rotation.
  • Easy, repeatable results – programmable touchscreen control with USB recipe upload/download.
  • Labor-saving operation – no watching, no rotating and no flavor transfer between menu items.
  • Waterless design – no drains, filters or plumbing; lowers installation and operating costs.
  • Stainless steel durability – rugged exterior & interior with double-pane glass door and LED cavity lighting.
  • Ready out of the box – each chamber ships with 1 wire rack and 2 jet plates.
  • ChefLinc™ cloud connectivity (with Deluxe control) for remote oven management and data-driven insights.
  • cULus listed & UL EPH Classified for food-service safety and sanitation.

Included with the F3G

  • (3) Individually controlled cooking chambers
  • (3) Wire racks – one per chamber
  • (6) Jet plates – two per chamber for Structured Air Technology®
  • Programmable touchscreen control panel
  • USB port for recipe transfer & HACCP data

Popular add-ons (sold separately)

  • Single-point quick-release temperature probe (PR-35770)
  • 3" swivel casters or mobile base for easy movement
  • Additional wire racks & jet plate assemblies
  • Alto-Shaam non-caustic oven cleaner (32 oz or case)

Performance specifications

Model Vector F Series F3G (Gas)
Cooking chambers 3 independent chambers
Total pan capacity 3 full-size (18" × 26") or 6 half-size (18" × 13") sheet pans
Temperature range 200 °F – 525 °F (93 °C – 274 °C)
Chamber height 4-5/16" (109 mm) each  |  11-1/4" (287 mm) combined
Exterior dimensions (H × W × D) 34-9/16" × 41" × 46-1/8" (878 × 1041 × 1172 mm)
Net weight 556 lb (252 kg)
Gas connection 3/4" NPT  |  72,000 BTU/hr (natural or propane)
Electrical connection 120 V / 1 ph / 60 Hz – 1.5 kW (12.7 A)
208–240 V / 1 ph / 50-60 Hz – 1.7 kW (8.3 A)
Noise level Max 72 dBA at 3.3 ft (1 m)
Certifications cULus, UL EPH, ANSI Z83.11b-CSA 1.8b

Clearance & installation

  • Minimum clearance: 2" (51 mm) left & right, 4" (102 mm) rear
  • Exhaust hood required; oven is not intended for built-in installation
  • Unit must sit level on a non-combustible surface
Important: A factory-authorized site survey and installation are recommended. Improper installation may void the manufacturer’s warranty.

Images may show optional accessories and Deluxe control. Stands, casters and probes sold separately.

Features & Specs

Manufacturer

Alto-Shaam

Brand_name

Vector Series

Certifications

cULus, UL EPH Classified

Height

36.56in

Width

41.0in

Depth

44.25in

Shipping Weight

610.0lbs

Half Size Sheet Pan Capacity

(6) 13" x 18" pans

Full Size Sheet Pan Capacity

(3) 18" x 26" pans

Control Type

programmable controls

Specifications

Vector® F Series Multi-Cook Oven, gas, (3) individually controlled cooking chambers, holds (6) half-size sheet pans (3) full sized sheet pans, programmable touch screen controls with Structured Air Technology®, double pane glass door, interior LED cavity lighting, includes: (1) wire rack & (2) jet plates per cooking chamber, USB port, stainless steel construction, cULus, UL EPH Classified
