Alto-Shaam 500-HW/D6 Halo Heat Steam Tables & Food Wells
Description
Alto-Shaam 500-HW/D6 Halo Heat® Drop-In Hot Food Well – 5 Full-Size Pans
Waterless, EcoSmart® holding technology for superior food quality & lower operating costs.Replace traditional steam tables with the gentle, radiant heat of Alto-Shaam’s patented Halo Heat®. The 500-HW/D6 delivers consistent, even holding temperatures without water, plumbing or fans—keeping menu items fresh, flavorful and ready to serve while saving on energy, labor and maintenance.
Why You’ll Love It
- Waterless Halo Heat® surrounds food evenly, extending hold times without drying or overcooking.
- Five 12" x 20" full-size pan capacity (6 in deep) – or mix & match with 1/2 and 1/3 pans using the included divider bars.
- Includes 10 half/third-size and 4 large pan divider bars for flexible merchandising.
- Adjustable thermostatic controller can be flush-mounted out of guests’ view for a clean counter line.
- No water means no lime or scale build-up, reduced maintenance and lower utility bills.
- 304 stainless steel well resists corrosion and cleans up quickly.
- EcoSmart® design is cULus, UL EPH Classified, CE, IPX3 and TÜV NORD listed for worldwide code compliance.
- Improved employee & guest safety—eliminates hot steam and boil-overs.
At-a-Glance Specs
| Model | 500-HW/D6 • Halo Heat® Hot Food Well |
|---|---|
| Pan Capacity | (5) full-size 12" × 20" pans (10) 1/2-size OR (15) 1/3-size pans |
| Well Depth | 6-3/8" (162 mm) – accepts pans up to 6" (150 mm) deep |
| Overall Dimensions (H × W × D) | 9-5/16" × 67-1/16" × 23-1/8" (235 × 1702 × 586 mm) |
| Counter Cut-out (non-combustible) | 66" × 22-1/8" (1676 × 562 mm) |
| Net Weight | 94.5 lb (43 kg) |
| Construction | 304 stainless steel well & flange |
| Controller | Flush-mount thermostatic knob, 1–10 dial |
| Electrical Options* |
• 120 V / 1 ph / 25 A / 3.0 kW – NEMA L5-30P • 208 V / 1 ph / 10.8 A / 2.3 kW – NEMA 6-15P • 240 V / 1 ph / 12.5 A / 3.0 kW – NEMA 6-15P • 230 V / 1 ph / 12 A / 3.0 kW – CEE 7/7 or BS 1363 |
| Certifications | cULus, UL EPH, CE, EcoSmart®, IPX3, TÜV NORD |
| Standard Accessories | (10) half/third-size & (4) large divider bars |
| Warranty | 1-year parts & labor (see Alto-Shaam warranty terms) |
*Select voltage & plug type when ordering.
What’s in the Box
- 500-HW/D6 drop-in hot food well
- (10) half/third-size pan divider bars
- (4) large pan divider bars
- Remote/flush-mount thermostatic control box with 6 ft (1.8 m) cord
- Owner’s manual & warranty documentation
Food pans shown in images are for illustration only and are not included. Always monitor food temperature and add overhead heat if required by local code.
