AERO Manufacturing

AERO Manufacturing MF3-2424-24L Three-Compartment Stainless Steel Sink, (3) 24 x 24 x 14 in Compartments, Left Drainboard, 7 in Backsplash

SKU: MF3-2424-24L
$4,393.19
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

3-compartment Sinks AERO Manufacturing Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks Compartment Sinks Equipment New Arrivals Plumbing & Water Treatment Restaurant Equipment Sinks & Handwashing Stations

The AERO Manufacturing MF3-2424-24L is an economy three-compartment stainless steel sink with three 24 in x 24 in x 14 in deep compartments and a 24 in left drainboard.

  • Includes a 7 in backsplash and two sets of 8 in on-center splash-mount faucet holes.
  • Constructed with 16-gauge 304 stainless steel and supported by 16-gauge 430 stainless steel legs with adjustable stainless steel feet.
  • Features raised rolled edges, fully welded stainless steel gussets, and the AERO Hemmed Safety Edge.
  • Knock-down construction; supplied with a stainless steel drain basket and strainer.

Overall Dimensions:

100.25"W x 30.0"D x 39.5"H

Product Weight:

200.0 lb

Three-compartment configuration

Provides three fabricated compartments, each measuring 24 in wide by 24 in front-to-back by 14 in deep.

Left drainboard

Includes a 24 in drainboard positioned on the left side.

Backsplash and faucet holes

Features a 7 in backsplash with two sets of 8 in on-center splash-mount faucet holes.

Stainless steel construction

Uses 16-gauge 304 stainless steel construction with 16-gauge 430 stainless steel legs.

Adjustable stainless steel feet

The stainless steel legs are fitted with adjustable stainless steel feet.

Welded support and finished edges

Includes fully welded stainless steel gussets, raised rolled edges on the front and sides, and the AERO Hemmed Safety Edge.

Drain hardware

Supplied with a stainless steel drain basket and strainer.

Knock-down design

The sink is specified as KD construction.

Sink type Economy three-compartment sink
Number of compartments 3
Compartment size 24 in W x 24 in front-to-back x 14 in deep, each
Drainboard 24 in left drainboard
Backsplash height 7 in
Faucet holes Two sets, 8 in on center
Top gauge 16 gauge
Top stainless series 300 series
Construction material 304 stainless steel
Leg material 16-gauge 430 stainless steel
Feet Adjustable stainless steel feet
Edge detail Raised rolled edges on front and sides; AERO Hemmed Safety Edge
Support Fully welded stainless steel gussets
Assembly Knock-down construction
Drain hardware Stainless steel drain basket and strainer
Overall width 100.25 in
Overall depth 30 in
Overall height 39.5 in
Weight 200 lb

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

It has three compartments, each measuring 24 in wide by 24 in front-to-back by 14 in deep.
The 24 in drainboard is on the left side.
The backsplash is 7 in high.
The sink has two sets of 8 in on-center splash-mount faucet holes.
No. The product documentation specifies that faucets are not included.
The overall dimensions are 100.25 in wide by 30 in deep by 39.5 in high.
