AERO Manufacturing 3F2-3020-30LR 2-Compartment Stainless Steel Sink, 103"W, 16-Gauge 304, 30" Left/Right Drainboards, 14"D Basins

SKU: 3F2-3020-30LR
$4,305.71
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

AERO Manufacturing Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks Compartment Sinks Equipment New Arrivals Plumbing & Water Treatment Restaurant Equipment Sinks & Handwashing Stations

AERO Manufacturing 3F2-3020-30LR is a Delux™ two-compartment stainless steel sink measuring 103 inches wide, 36 inches deep, and 39.5 inches high.

  • Two fabricated compartments measuring 20 inches wide by 30 inches front-to-back by 14 inches deep
  • 30-inch drainboards on the left and right sides
  • 16-gauge 304 stainless steel construction with a 7-inch backsplash
  • 8-inch on-center faucet holes, raised rolled edges, fully welded stainless steel gussets, and adjustable stainless steel feet
  • Includes the Aero Hemmed Safety Edge™ and is specified as KD for knock-down assembly

Overall Dimensions:

103.0"W x 36.0"D x 39.5"H

Product Weight:

185.0 lb

Two fabricated compartments

Includes two compartments measuring 20 inches wide by 30 inches front-to-back by 14 inches deep.

Left and right drainboards

Provides 30-inch drainboards on both sides of the sink.

304 stainless steel construction

Uses 16-gauge 304 stainless steel for the sink construction and legs.

Backsplash and faucet holes

Includes a 7-inch backsplash and 8-inch on-center faucet holes.

Aero Hemmed Safety Edge™

Features the specified Aero Hemmed Safety Edge™ along with raised rolled edges on the front and sides.

Welded gusset support

Uses fully welded stainless steel gussets.

Adjustable stainless steel feet

The stainless steel legs are fitted with adjustable stainless steel feet.

Drain basket and strainer

Supplied with a stainless steel drain basket and strainer.

Product Type Two-compartment sink with two drainboards
Overall Dimensions 103 in W x 36 in D x 39.5 in H
Compartment Dimensions (2) 20 in W x 30 in front-to-back x 14 in deep
Material 16-gauge 304 stainless steel
Drainboards 30 in left and right drainboards
Backsplash Height 7 in
Faucet Hole Spacing 8 in on center
Legs 16-gauge 304 stainless steel legs
Feet Adjustable stainless steel feet
Edge Design Aero Hemmed Safety Edge™; raised rolled edges on front and sides
Support Fully welded stainless steel gussets
Assembly KD (knock-down)
Weight 185 lb
Certification NSF

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

It has two fabricated compartments.
Each compartment measures 20 inches wide by 30 inches front-to-back by 14 inches deep.
The sink measures 103 inches wide by 36 inches deep by 39.5 inches high.
Yes. It has 30-inch drainboards on the left and right sides.
The faucet holes are spaced 8 inches on center.
No. The cutsheet states that faucets are not included.
It has a 7-inch backsplash.
Yes. It is supplied with a stainless steel drain basket and strainer.
