AERO Manufacturing

AERO Manufacturing 3C3-1414-14LR 3-Compartment Corner Sink, 46-3/4"W x 20"D, 14" Bowls, Left/Right Drainboards, 304 Stainless Steel

SKU: 3C3-1414-14LR
$3,471.52
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

3-compartment Sinks AERO Manufacturing Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks Compartment Sinks Equipment New Arrivals Plumbing & Water Treatment Restaurant Equipment Sinks & Handwashing Stations

The 3C3-1414-14LR is a three-compartment corner sink constructed from 16-gauge 304 stainless steel.

  • Three fabricated compartments measure 14 inches wide by 14 inches front to back and 14 inches deep.
  • Includes 14-inch drainboards on the left and right sides.
  • Features a 7-inch backsplash and two sets of 8-inch on-center faucet holes.
  • Includes fully welded stainless steel gussets, adjustable white metal feet, and the Aero Hemmed Safety Edge™.

Overall Dimensions:

46.75"W x 20.0"D x 39.5"H

Product Weight:

100.0 lb

Three compartments

Includes three fabricated compartments, each measuring 14 inches wide by 14 inches front to back and 14 inches deep.

Left and right drainboards

Includes a 14-inch drainboard on each side.

304 stainless steel construction

The sink body and legs use 16-gauge 304 stainless steel.

7-inch backsplash

A 7-inch backsplash is included.

Faucet holes

Includes two sets of faucet holes spaced 8 inches on center.

Welded gussets

Features fully welded stainless steel gussets.

Adjustable feet

The stainless steel legs include adjustable white metal feet.

Aero Hemmed Safety Edge™

Includes the Aero Hemmed Safety Edge™.

KD design

The sink is specified as KD.

Product type Three-compartment corner sink
Construction material 16-gauge 304 stainless steel
Compartments 3
Compartment size 14 in W x 14 in front to back x 14 in deep
Drainboards 14 in, left and right
Backsplash height 7 in
Faucet holes 2 sets, 8 in on center
Gussets Fully welded stainless steel
Legs 16-gauge 304 stainless steel
Feet Adjustable white metal
Assembly KD
Overall width 46-3/4 in
Overall depth 20 in
Overall height 39-1/2 in

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

It has three fabricated compartments.
Each compartment measures 14 inches wide by 14 inches front to back and 14 inches deep.
The sink measures 46-3/4 inches wide by 20 inches deep by 39-1/2 inches high.
Yes. It includes 14-inch drainboards on the left and right sides.
It has two sets of faucet holes spaced 8 inches on center.
The sink uses 16-gauge 304 stainless steel construction, including the legs.
Yes. It has a 7-inch backsplash.
Yes. NSF is listed for this product.
