Advance Tabco TVKG-363 Stainless Steel Prep Tables
Description
Advance Tabco 36" x 36" SPEC-LINE Work Table with 10" Backsplash – Galvanized Base
Model TVKG-363 | 14-Gauge 304 Stainless Steel Top | NSFEngineered for demanding commercial kitchens, the Advance Tabco TVKG-363 delivers a rugged 36" square work surface while keeping your walls and floors protected from spills and splashes. A heavy-duty 14-gauge type 304 stainless-steel top, reinforced with stud-welded hat channels, sits on a galvanized open-base frame that leaves plenty of room below for ingredient bins, carts or trash receptacles.
Key Features
- 14-gauge type 304 stainless-steel top – thicker, stronger and more dent-resistant than 16- or 18-gauge tops.
- 2" x 1" die-formed No-Drip edge with ½" return on three sides prevents liquid runoff.
- Factory-welded 10" backsplash with 2" return shields walls and meets health-code splash requirements.
- (3) roll-formed galvanized hat channels are stud-welded under the top to eliminate flex and keep the surface level.
- Open-base frame with 1 5⁄8" O.D. galvanized legs plus 1 5⁄8" rear & 1 ¼" side tubular cross-bracing for superior stability.
- 1" adjustable plastic bullet feet for quick leveling and corrosion resistance against mop water.
- Top is sound-deadened and polished to a sanitary satin finish; countertop edge receives a mirror polish for a premium look.
- NSF listed for use in all food-zone applications.
Performance Load Rating
Advance Tabco rates a 14-gauge work-table top up to 60" long at 1,000 lb distributed load. This model includes a 10" backsplash (+10 % capacity) and an open base (–20 % capacity), resulting in an estimated 880 lb distributed load rating.*
*Rating applies to evenly-distributed static loads only.
Specifications
| Model | TVKG-363 |
|---|---|
| Overall Dimensions | 36" L × 36" D × ≈35 ½" H (work surface) |
| Backsplash | 10" H with 2" return |
| Top Material | 14-ga type 304 stainless steel, sound-deadened, satin finish |
| Countertop Edge | 2" × 1" No-Drip square edge, ½" return on three sides |
| Reinforcement | (3) galvanized hat channels, stud-welded |
| Legs | 1 5⁄8" O.D. galvanized steel, 16-ga |
| Cross-Bracing | Rear – 1 5⁄8" tubular galvanized Side – 1 ¼" tubular galvanized |
| Feet | 1" adjustable plastic bullet style |
| Base Style | Open (no undershelf) |
| Ship Weight | 80 lb |
| Certifications | NSF |
Ideal Applications
- Produce, meat or pastry prep stations
- Assembly tables in commissaries, ghost kitchens or catering operations
- Packaging / plating lines that require frequent sanitation
- Any 36" footprint where wall splash protection is critical
The SPEC-LINE series is pre-engineered for easy accessory installation. Ask us about Advance Tabco Smart Fabrication™ options to customize your workstation.
Specifications are subject to change without notice.
