Advance Tabco TA-521 12-Inch Drop-In Stainless Steel Urn Trough with Louvered Cover and Drain

SKU: TA-521
GTIN: 747545153883
$107.00
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Advance Tabco Bar Equipment Best Sellers Beverage Equipment Beverage Equipment Ice Machines & Beverage Equipment New Arrivals Restaurant Equipment

Advance Tabco TA-521 12-Inch Drop-In Stainless Steel Urn Trough with Louvered Cover and Drain

Field Installation Only, Requires 5 1/8-Inch Countertop Opening

A compact 12-inch drop-in urn trough built for clean field installation, dependable drainage, and durable stainless steel service.

  • Drop-in urn trough designed for field installation in a countertop opening.
  • Includes a slotted louvered cover plate and a 1 1/2-inch IPS drain.
  • Constructed from 16-gauge type 304 stainless steel with a satin finish.
  • 1-inch flange on all four sides supports the trough in the countertop.
  • All TIG welded construction helps provide lasting durability.
  • Custom lengths are available; consult the factory.

Overall Dimensions:

14.0"W x 7.0"D x 1.25"H

Product Weight:

3.0 lb

Field Installation Only

Designed for field installation rather than factory installation.

5 1/8-Inch Countertop Opening

Requires a 5 1/8-inch wide opening in the countertop.

Countertop Support Flange

A 1-inch flange on all four sides supports the trough in the countertop.

16-Gauge 304 Stainless Steel

Durable stainless steel construction with exposed surfaces polished to a satin finish.

TIG Welded Construction

All TIG welded for strength and long-term reliability.

Slotted Louvered Cover Plate

Includes a slotted urn trough cover plate.

1 1/2-Inch IPS Drain

Built with a 1 1/2-inch IPS drain connection.

Custom Lengths Available

Custom lengths are available; consult the factory.

Type Urn Trough
Style Drop-In
Installation Type Countertop
Material 304 Stainless Steel
Finish Satin Finish
Drain Connection Size 1 1/2 Inches IPS
Selling Unit Each
Units Per Case 1
Shipping Width 14 Inches
Shipping Depth 7 Inches
Shipping Height 2 Inches
Shipping Weight 3 lb.

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The document states that it requires a 5 1/8-inch wide countertop opening; the TA-521 cut-out dimensions are listed as 5 1/4 inches x 12 1/4 inches.
Yes. It includes a slotted louvered cover plate and a 1 1/2-inch IPS drain.
It is made from 16-gauge type 304 stainless steel with exposed surfaces polished to a satin finish.
No. The TA-521 is for field installation only. The document refers buyers to TA-64 for factory installation.
Yes. The document states that custom lengths are available and suggests consulting the factory.
