Advance Tabco PT-18S-96 Stainless Steel Shelving
Description
Advance Tabco PT-18S-96 Stainless Steel Overshelf
96" W x 18" D • Single-tier • Splash-mountedInstantly expand your prep or plating space with this heavy-duty, splash-mounted overshelf from Advance Tabco’s Mix-&-Match adjustable series. Built entirely of stainless steel, the PT-18S-96 adds a full 8 linear feet of overhead storage without sacrificing valuable work-surface real estate.
Why You’ll Love It
- Generous capacity: 96 in. long by 18 in. deep shelf holds smallwares, ingredients, or countertop appliances.
- Splash-mount design: 1 ½ in. rear up-turn locks firmly to the table backsplash and keeps items from sliding off the back.
- Adjustable height: Shelf collar glides along sturdy 1 5/8 in. Ø tubular uprights—set it exactly where you need it.
- Maximum work-area clearance: Single-post uprights require only one penetration through the table, freeing up the entire top for production.
- All-stainless construction: Shelf, uprights, gussets, and hardware resist corrosion, simplify sanitation, and present a professional look.
- TIG-welded & polished: Smooth, easy-to-wipe surfaces stand up to daily commercial abuse.
- Field compatible: Fits Advance Tabco flat-top or splash-top worktables and most open-base units.
Technical Specs
| Model | PT-18S-96 |
|---|---|
| Shelf length | 96 in. (2438 mm) |
| Shelf depth (front → back) | 18 in. (457 mm) |
| Rear splash height | 1 ½ in. (38 mm) |
| Mount type | Splash mount (attaches to table backsplash) |
| Upright diameter | 1 5/8 in. (41 mm) tubular stainless steel |
| Overall adjustable height* | Up to 60 in. A.F.F. with shelf only *Height may vary based on table and user preference. |
| Approx. shipping weight | 31 lb. (14 kg) |
| Material finish | Stainless steel, satin polish |
Simple Installation
- Pre-drilled splash brackets align with Advance Tabco table backsplashes.
- Set-screw gussets lock the shelf in place—no cutting or welding required.
- All mounting hardware is included.
Need additional storage? This overshelf is part of Advance Tabco’s Mix-&-Match system—pot racks and utensil racks can be added later using the same uprights.
