Advance Tabco  |  SKU: PT-18S-144  |  UPC: 747545147165

Advance Tabco PT-18S-144 Stainless Steel Shelving

$1,416.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

144" x 18" Stainless Steel Splash-Mounted Overshelf

Advance Tabco Mix & Match Series – Model PT-18S-144

Instantly expand your prep & storage capacity with this single, 18" deep overshelf. Engineered for Advance Tabco worktables, the PT-18S-144 mounts directly to the table’s rear splash, giving you a rock-solid upper level while keeping every inch of the tabletop free for production.

Key Features

  • Heavy-duty all-stainless steel construction for maximum corrosion resistance and easy sanitation.
  • Splash-mount design attaches to the existing 1 ½" backsplash—no additional holes in the work surface.
  • Single 1 5/8" Ø tubular uprights at each end minimize tabletop obstructions.
  • Rolled rim front edge for operator safety; square ends for tight, flush installations.
  • 1 ½" rear splash on shelf contains spills and prevents wall damage.
  • Fully adjustable height along the uprights; lock in place with gusset-style set screws.
  • TIG-welded seams with polished finish to match Advance Tabco worktables.
  • Compatible with optional pot rack and utensil rack components (sold separately).

At-a-Glance Specifications

Shelf length 144" (12 ft)
Shelf depth 18"
Mounting style Splash-mounted (TA-227 assembly)
Rear splash height 1 ½"
Upright diameter 1 5/8"
Recommended shelf height Approx. 60" A.F.F. (adjustable)
Material Stainless steel (shelf, uprights, gussets & hardware)
Shipping weight 43 lb

Ideal For

  • Expanding dry storage above prep tables
  • Keeping frequently used ingredients or smallwares within easy reach
  • High-volume kitchens needing a durable, NSF-friendly overshelf solution
Installation Note: This overshelf is designed for factory or professional installation on Advance Tabco tables with an existing 1 ½" rear splash. Verify table compatibility before ordering.

Looking to create a full overhead workstation? Add a matching pot rack or utensil rack from the Advance Tabco Mix & Match series for a totally customized setup.

Features & Specs

Manufacturer

Advance Tabco

Height

6.25in

Width

144.0in

Depth

18.0in

Shipping Weight

43.0lbs

Depth (front - back)

18"

Shelves

single

Construction

stainless steel

Width (side - side)

133" - 144"

Specifications

Overshelf, table mounted, single, 144"W x 18"D, stainless steel, uprights of shelf, splash mounted
