Advance Tabco PR-44X42SP-10-L Prestige (Supreme) Bar Equipment
Description
Advance Tabco Prestige® “Supreme” Double Service Station
Model PR-44x42SP-10-L | 44" W x 52" D Pass-Thru WorkstationEngineered for high-volume bars that refuse to compromise on speed or sanitation, the Prestige “Supreme” Double Service Station combines a 174 lb ice bin, dual hand-wash sinks and a 10-circuit cold plate into one seamless, NSF-listed workstation. The left-side pass-thru ice bin keeps bartenders on both sides supplied, while the right-side sinks satisfy hand-wash codes without forcing staff to leave the drink line.
Why You’ll Love It
- 174 lb Pass-Thru Ice Bin (Left) – Fully foam-insulated and fitted with a 10-circuit cast-aluminum cold plate for fountain lines.
- Double Deep-Drawn Sinks – 9" × 9" × 4 ½" seamless bowls with a deck-mounted K-51 swing-spout faucet on the right.
- Built-In Tubing Chase – Keeps soda gun lines and electrical neatly routed away from splash zones.
- Blender Shelf + GFI Outlet – 20-ga. stainless steel shelf with a recessed, 15 A/120 V duplex receptacle beneath.
- Double-Tier Speed Rail – 22-ga. rail with 16-ga. ends holds your most-used bottles at chest height.
- Perforated Drainboard Shelf – Stainless shelf spans the side panels, allowing glassware to air-dry above the floor.
- All-Stainless Construction – 300-series throughout; side-panel design eliminates front legs for clear, open access.
Technical Specifications
| Overall dimensions | 44" W × 52" D × 29" H (work surface) |
|---|---|
| Ice capacity | 174 lb (foam-insulated) |
| Cold plate | Cast aluminum, 10 sealed circuits |
| Sinks | (2) 9" × 9" × 4 ½" deep-drawn bowls |
| Faucet | K-51 deck-mount, 4" O.C. swing spout |
| Electrical | 15 A / 120 V GFI duplex under blender shelf |
| Material thickness | 20-ga. top/sinks/ice bin | 22-ga. front apron & speed rail | 18-ga. side panels |
| Shipping weight | Approx. 575 lb |
| Listings | NSF / ANSI 2 & NSF / ANSI 61, Section 9 (lead-free) |
What’s Included
- Prestige® SP Series pass-thru workstation, left-hand ice bin
- 10-circuit cold plate, factory-sealed
- (2) deep-drawn hand sinks with basket drains
- K-51 lead-free swing-spout faucet
- Integrated tubing chase for soda gun lines
- Blender shelf with recessed GFI outlet
- Double-tier stainless speed rail
- Side panels with perforated drainboard shelf
- Installation & plumbing hardware
Need a sliding ice bin cover or overshelf? Factory-installed accessories are available— please contact us for a custom quote before ordering.
